Hubbell
239 RACO 4SQ PLENUM BOX 2-1/8 DEEP 1/2-3/4 KO

Mouse over image to zoom, click to enlarge

  • 239 RACO 4SQ PLENUM BOX 2-1/8 DEEP 1/2-3/4 KO
  • 239 RACO 4SQ PLENUM BOX 2-1/8 DEEP 1/2-3/4 KO
  • 239 RACO 4SQ PLENUM BOX 2-1/8 DEEP 1/2-3/4 KO
  • 239 RACO 4SQ PLENUM BOX 2-1/8 DEEP 1/2-3/4 KO
  • 239 RACO 4SQ PLENUM BOX 2-1/8 DEEP 1/2-3/4 KO

Description: EATON Bussmann Circuit Protector Disconnect Switch, Compact Fused, 347 V AC/125 V DC, 30 A, 1 Pole, 35 mm DIN Rail Mount, Switch Handle Operator, -4 to 167 deg F Operating, 0.3 in W, 3.7 in Height

Manufacturer PN: 239

UPC:  05016900239

Kendall Electric Inc PN: 3891663

Invoice Description:

CCP2-1-30CC BUS FUSBL CT PROTR (6)


SPEC SHEET

▸ See All in Square Boxes


How Can We Make This Page Better?

EATON Bussmann CCP2-1-30CC Compact Fused Circuit Protector Disconnect Switch, 347 V AC/125 V DC, 30 A, 1 Poles

Log In for Pricing and Availability




Description

The revolutionary Bussmann™ series CCP with CUBEFuse™ is a fused branch circuit disconnect that requires up to 67% less space with ratings up to 600A. The CCP with CUBEFuse simplifies selective coordination and allows for isolation of individual branch circuit loads for safe work practices.
EATON Bussmann Circuit Protector Disconnect Switch, Compact Fused, 347 V AC/125 V DC, 30 A, 1 Pole, 35 mm DIN Rail Mount, Switch Handle Operator, -4 to 167 deg F Operating, 0.3 in W, 3.7 in Height

Specifications

 Amperage Rating 30 A
 Brand Name EATON
 Height 3.7 in
 Manufacturer Part Number CCP2-1-30CC
 Mounting Type 35 mm DIN Rail
 Number of Poles 1
 Operating Temperature -4 to 167 deg F
 Operator Switch Handle
 PART NUMBER KEYWORDS CCP2-1-30CC ; CCP2130CC ; 14584476 ; 051712709163 ; 51712709163 ; 05171270916 ; 00051712709163
 Standards/Approvals UL 98 File No. E302370, Guide WHTY|cULus to Canadian Standard 22.2 No. 4-04|UL File No. E302370, Guide WHTY7|CE Certified
 Type Compact Fused
 Voltage Rating 347 V AC/125 V DC
 Width 0.3 in

Features

▪ Extremely compact (18 mm wide per pole ) design
▪ Disconnect rated for load isolation
▪ IEC 10x38 version complies with IEC 60947-3 and suitable for branch circuit protection and disconnect
▪ Suitable for global installations, the switches comply with UL, cULus and IEC standards accepting UL class CC, supplemental or IEC aM and gG/gL fuses
▪ Open fuse indication - standard local open fuse indicating light for each pole
▪ IP20 finger-safe with 10 AWG or larger wire (box lug terminals only)
▪ Built-in switch interlock prohibits removing the fuse under load
▪ Padlockable handle for lockout/tagout - 4 mm lock for switch only
▪ 1/4 in lock for rotary operated switches
