Schneider Electric
  • ZB5AC2 SQD MOMENTARY MUSHROOM 40MM
  • ZB5AC2 SQD MOMENTARY MUSHROOM 40MM
  • ZB5AC2 SQD MOMENTARY MUSHROOM 40MM
  • ZB5AC2 SQD MOMENTARY MUSHROOM 40MM
  • ZB5AC2 SQD MOMENTARY MUSHROOM 40MM
  • ZB5AC2 SQD MOMENTARY MUSHROOM 40MM

Description: Schneider Electric Harmony™ Square D™ Pushbutton Head, Mushroom Non-Illuminated Momentary Standard Unmarked, Series: ZB5, 22 mm Size, Round Shape, Plastic, Black

Manufacturer PN: ZB5AC2

UPC:  38911090486

Kendall Electric Inc PN: 3960010

Invoice Description:

ZB5AC2 SQD MOMENTARY MUSHROOM 40MM


SPEC SHEET

How Can We Make This Page Better?

Schneider Electric Harmony™ Square D™ ZB5AC2 Mushroom Non-Illuminated Momentary Standard Unmarked Pushbutton Head, 22 mm, Round Shape, Plastic, Black

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

This Harmony XB5, 40mm mushroom black button head operates with a spring return mechanism. This 40mm mushroom shaped push-button head is ideal for situations where quick actions are required for a process or machine to function correctly or where operator movements require maximum ergonomy. It is easily combined with Harmony range of contact blocks to perform a large variety of control functions. It is clearly distinguishable visually at a distance thanks to a prominent 40mm mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
Schneider Electric Harmony™ Square D™ Pushbutton Head, Mushroom Non-Illuminated Momentary Standard Unmarked, Series: ZB5, 22 mm Size, Round Shape, Plastic, Black

Specifications

 Application Control and Signaling Applications
 Brand Name Square D
 Color Black
 Manufacturer Part Number ZB5AC2
 Material Plastic
 PART NUMBER KEYWORDS ZB5AC2 ; 8015578 ; 785901376316 ; 78590137631 ; 03389110904864 ; 3389110904864
 Series ZB5
 Shape Round
 Size 22 mm
 Standards/Approvals RoHS Compliant|UL 508 File No. E164353 CCN NKCR|CSA C22.2 No. 14 File No. LR44087 Class 3211 03|CE Certified|EN/IEC 60947-1|EN/IEC 60947-5-1|EN/IEC 60947-5-4|JIS C 4520|BV Certified|DNV Certified|GL Certified|Lloyd's Register Certified|RINA Certified|ECCN: EAR99|PROP65: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
 Type Mushroom Non-Illuminated Momentary Standard Unmarked

Features

▪ Quick and easy assembly and disassembly
▪ Robustness to withstand harsh environments
▪ With various types of connection - screw clamp, connector, Faston connector, spring terminal, or printed circuit board
▪ Excellent mechanical connection with operator head
▪ A large set of accessories to customize your panels
