Schneider Electric
ZB4BW035 SQD MOUNTING COLLAR W 120V

Mouse over image to zoom, click to enlarge

Description: Schneider Electric Harmony™ Complete Body/Light Block/Contact Assembly, Slow Break Standard, Series: ZB4, 22 mm Dia Size, Incandescent Lamp, 110 to 120 V AC, Screw Clamp Terminal, Flush Mounting, Silver Alloy, 1.18 in W x 1.85 in H Dimensions

Manufacturer PN: ZB4BW035

UPC:  38911089183

Kendall Electric Inc PN: 4001080

Invoice Description:

ZB4BW035 SQD MOUNTING COLLAR W 120V


SPEC SHEET

▸ See All in Pushbutton & Switch Lamp Modules


How Can We Make This Page Better?

Schneider Electric Harmony™ ZB4BW035 Slow Break Standard Complete Body/Light Block/Contact Assembly, 22 mm Dia, Incandescent Lamp, 110 to 120 V AC, Screw Clamp Terminal

Log In for Pricing and Availability

Note: Lead times are estimates only




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

This Harmony XB4, light block with body/fixing collar isoperates with BA9s base Integral LED. It has 1 x NO + 1 x NC contacts and a metal body and is compatible with Harmony XB4 pilot lights. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by BA9s base Integral LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. It is designed to fit with a standard 22mm control and signaling units, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 55°C allows versatility in usage of product.
Schneider Electric Harmony™ Complete Body/Light Block/Contact Assembly, Slow Break Standard, Series: ZB4, 22 mm Dia Size, Incandescent Lamp, 110 to 120 V AC, Screw Clamp Terminal, Flush Mounting, Silver Alloy, 1.18 in W x 1.85 in H Dimensions

Specifications

 Application Xb4 Chromium Plated Metal Bezel Round Pushbuttons and Pilot Lights
 Brand Name Square D
 Dimensions 1.18 in W x 1.85 in H
 Includes Mounting Collar, Contact Block, Light Module and Bulb
 Lamp Type Incandescent
 Manufacturer Part Number ZB4BW035
 Material Silver Alloy
 Mounting Type Flush
 PART NUMBER KEYWORDS ZB4BW035 ; 8077051 ; 785901891833 ; 78590189183 ; 03389110891836 ; 3389110891836
 Series ZB4
 Size 22 mm Dia
 Standards/Approvals RoHS Compliant|CSA C22.2 14|EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, EN/IEC 60947-5-5|UL 508|Green Premium|REACH Compliant|WEEE Compliant|ECCN: EAR99|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
 Terminal Type Screw Clamp
 Type Slow Break Standard
 Video Links
 Voltage Rating 110 to 120 V AC

Features

▪ This Schneider Electric Harmony XB4 light block with body/fixing collar isoperates with BA9s base Integral LED
▪ It is supplied with a 110 to 120Vac/dc and uses screw-clamp terminals
▪ It has 1 x NO + 1 x NC contacts and a metal body and is compatible with
