Eaton
XTMCC9A10TD CH MINI CONTACTOR 3P FVNR CG 9A FRAME A 1NO 24VDC COIL

Mouse over image to zoom, click to enlarge

  • XTMCC9A10TD CH MINI CONTACTOR 3P FVNR CG 9A FRAME A 1NO 24VDC COIL
  • XTMCC9A10TD CH MINI CONTACTOR 3P FVNR CG 9A FRAME A 1NO 24VDC COIL
  • XTMCC9A10TD CH MINI CONTACTOR 3P FVNR CG 9A FRAME A 1NO 24VDC COIL

Description: EATON IEC Miniature Contactor, Full Voltage Non-Reversing, Series: XTMC, 24 V DC Coil, 8.8 A Maximum Load Current, 5 hp at 575 VAC 1/3 ph Coil Power Rating, 3 Pole, 1NO, 45 mm, Spring Cage Terminal, DIN Rail/Panel Mount

Manufacturer PN: XTMCC9A10TD

UPC:  01508230165

Kendall Electric Inc PN: 4156341

Invoice Description:

XTMCC9A10TD CH MINI CONTACTOR 3P FVNR CG 9A FRAME A 1NO 24VDC COIL


SPEC SHEET

▸ See All in NEMA & IEC Contactors


How Can We Make This Page Better?

EATON XTMCC9A10TD Full Voltage Non-Reversing IEC Miniature Contactor, 24 V DC V Coil, 8.8 A, 1NO Contact, 3 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The XT IEC contactors are powerful, efficient and versatile, and can be combined with our full range of electronic overload relays and bimetal relays. These DC devices stand out for their reduced power consumption, which makes them more energy efficient and also reduces the size of the power supply units. XT IEC contactors are suitable for global use and cover the entire output range, from mini contactor relays (up to 7 A) all the way to vacuum contactors (up to 3180 A).
EATON IEC Miniature Contactor, Full Voltage Non-Reversing, Series: XTMC, 24 V DC Coil, 8.8 A Maximum Load Current, 5 hp at 575 VAC 1/3 ph Coil Power Rating, 3 Pole, 1NO, 45 mm, Spring Cage Terminal, DIN Rail/Panel Mount

Specifications

 Brand Name EATON
 Coil Power Rating 5 hp at 575 VAC 1/3 ph
 Coil Voltage 24 V DC
 Contact Configuration 1NO
 Manufacturer Part Number XTMCC9A10TD
 Maximum Load Current 8.8 A
 Mounting Type DIN Rail/Panel
 Number of Poles 3
 PART NUMBER KEYWORDS XTMCC9A10TD ; 11232204 ; 04015082301651 ; 4015082301651
 Series XTMC
 Size 45 mm
 Standards/Approvals CSA Certified,IEC 60947,EN 60947,UL Listed,CE Marked,RoHS Compliant
 Terminal Type Spring Cage
 Type Full Voltage Non-Reversing
 Video Links

Features

▪ 1/2 hp at 115 VAC 1/3 ph, 1.5/2 hp at 200 VAC 1/3 ph, 3 hp at 200/230 VAC 1/3 ph, 5 hp at 460 VAC 1/3 ph, 5 hp at 575 VAC 1/3 ph coil power rating
