Description: Hubbell® Wall Mount Occupancy Sensor, Digital, Series: WASP2, 120/277/347 V AC, 30 mA, Passive Infrared Sensor, 30 to 2500 ft Coverage, 180/360 deg Viewing, 8 s Test Delay, Automatic On/Automatic Off Control Output, 12-Pin Dip Switch Interface, NEMA/IP65, -40 to 149 deg F, Plastic, White, 4 in Dia x 1-1/2 in H

Manufacturer PN: WSPEMUNVLWO-D

Kendall Electric Inc PN: 3568440

Invoice Description:

WSPEMUNVLWO-D HUBBELL


SPEC SHEET

▸ See All in Fixture Mount Occupancy Sensors


How Can We Make This Page Better?

Hubbell® WSPEMUNVLWO-D WASP2 Digital Wall Mount Occupancy Sensor, 120/277/347 V AC, Passive Infrared Sensor, 30 to 2500 ft Coverage, 180/360 deg Viewing

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The WASP2 Indoor/Outdoor Occupancy Sensor is specifically designed for ON/OFF control of high bay fixtures in warehouse, distribution centers and similar facilities. The WASP2 sensor is also available for low mount applications when using the appropriate lens. The sensor is available in end mount and surface mount versions with either single or dual outputs. All WASP2 sensors feature a daylight sensor which can be used to increase energy savings by turning off lights when there is sufficient natural light detected. These sensors also have a unique feature known as "Smart Cycling" which ensures even lamp burn time within the fixture. Using the "Smart Cycling" feature, the amount of time each lamp is burned is maintained and kept balanced.
Hubbell® Wall Mount Occupancy Sensor, Digital, Series: WASP2, 120/277/347 V AC, 30 mA, Passive Infrared Sensor, 30 to 2500 ft Coverage, 180/360 deg Viewing, 8 s Test Delay, Automatic On/Automatic Off Control Output, 12-Pin Dip Switch Interface, NEMA/IP65, -40 to 149 deg F, Plastic, White, 4 in Dia x 1-1/2 in H

Specifications

 Amperage Rating 30 mA
 Application Indoor and Outdoor Applications
 Brand Name Hubbell®
 Color White
 Control Output Automatic On/Automatic Off
 Coverage 30 to 2500 ft
 Dimensions 4 in Dia x 1-1/2 in H
 Enclosure NEMA/IP65
 Interface 12-Pin Dip Switch
 Manufacturer Part Number WSPEMUNVLWO-D
 Material Plastic
 Sensor Type Passive Infrared
 Series WASP2
 Standards/Approvals UL Listed|cUL Listed
 Temperature Rating -40 to 149 deg F
 Time Delay 8 s Test
 Type Digital
 Viewing Angle 180/360 deg
 Voltage Rating 120/277/347 V AC

Features

▪ End mount sensor - downward and upward looking daylight sensors (Direction selectable via dip switch)
▪ High-impact, injection-molded plastic sensor module and lens assembly
▪ Mounts directly to end of fixture through extended 1/2 in chase nipple
▪ Digital passive infrared (PIR) sensor
▪ Supported mounting heights - high mount lens - 30 ft (9.14 m) outdoors 45 ft indoors (13.72 m) and low mount lens - 16 ft indoors/outdoors (4.88 m)
▪ Interchangeable high/low area detection lens options
▪ Daylight sensor for daylight harvesting applications
▪ Low temperature/water-tight/indoor-outdoor versions
▪ Withstands low temperature and conforms to IP65 water- tight standards
▪ 5 years limited warranty
▪ 12-Pin dip switch user interface
▪ Dual element pyrometer and spherical Fresnel lens designed for robust detection of a walking person
