Hubbell
WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH

Mouse over image to zoom, click to enlarge

  • WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH
  • WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH
  • WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH
  • WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH
  • WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH

Description: Wiring Device-Kellems H-MOSS® Occupancy Sensor Switch, Adjustable, Series: WS Series, 120/277 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, 20 s to 30 min Time Delay, Incandescent Lamp, Wire Lead Connection, Automatic/Manual On Control Output, Threaded Mounting, 32 to 122 deg F, ABS, White, 1.82 in W x 0.61 in D x 4.15 in H Dimensions

Manufacturer PN: WS2000W

UPC:  78358525629

Kendall Electric Inc PN: 3310417

Invoice Description:

WS2000W HUBBELL OCC/VAC SENSOR,PIR,120/277V,WH


SPEC SHEET

▸ See All in Wall Mount Occupancy Sensors


How Can We Make This Page Better?

Wiring Device-Kellems H-MOSS® WS2000W Adjustable Occupancy Sensor Switch, 120/277 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, Threaded Mount

Log In for Pricing and Availability




Description

Hubbell® WS/ATP series wall switches combine PIR sensing technology, photocell control and Hubbell® patented three wire method to provide the perfect light switch replacement solution. These sensors do not require a neutral connection and they have no minimum load requirements. The WS series has manual timer adjustment while the ATP series incorporates Hubbell® patented adaptive technology to automatically set timing and eliminate manual adjustments. The sensors come supplied with color matched faceplates. Manual-ON versions are available for enhanced savings. Four wire models support installations that require a neutral connection.
Wiring Device-Kellems H-MOSS® Occupancy Sensor Switch, Adjustable, Series: WS Series, 120/277 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, 20 s to 30 min Time Delay, Incandescent Lamp, Wire Lead Connection, Automatic/Manual On Control Output, Threaded Mounting, 32 to 122 deg F, ABS, White, 1.82 in W x 0.61 in D x 4.15 in H Dimensions

Specifications

 Application Single Circuit, Private Offices, Small Restrooms, Break Areas, Classrooms, Closets, Storage Areas and Indoor Dry Environment, LED and CFL Applications
 Brand Name Hubbell Premise Wiring
 Color White
 Connection Type Wire Lead
 Control Output Automatic/Manual On
 Coverage 1000 sq-ft
 Dimensions 1.82 in W x 0.61 in D x 4.15 in H
 Includes Nylon Wallplate
 Lamp Type Incandescent
 Manufacturer Part Number WS2000W
 Material ABS
 Mounting Type Threaded
 Sensor Type Passive Infrared
 Series WS Series
 Standards/Approvals CEC Title 24 Compliant|CSA Certified|cULus Listed|UL 773A|UL Listed
 Temperature Rating 32 to 122 deg F
 Time Delay 20 s to 30 min
 Type Adjustable
 Video Links
 Voltage Rating 120/277 VAC

Features

▪ Polyethylene lens
▪ Steel mounting strap
▪ 42 to 54 in above floor mounting height
▪ Red LED sensing indicator
▪ 20 to 90 Percent non-condensing relative humidity
▪ Tamper-resistant lens
▪ Designed for use on 120 or 277V AC circuits, no neutral required, fast retrofits. Built in photocell prevents lights from turning ON with sufficient natural light
▪ 3-Way capable
