Hubbell
WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630

Mouse over image to zoom, click to enlarge

  • WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630
  • WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630
  • WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630
  • WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630
  • WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630

Description: Wiring Device-Kellems H-MOSS® Occupancy Sensor Switch, 3-Way Adjustable, Series: WS Series, 120/277 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, 180 deg Viewing, 20 s to 30 min Time Delay, Incandescent Lamp, 60 Hz Response, Screw Terminal Connection, Automatic/Manual On Control Output, Threaded Mounting, 32 to 122 deg F, ABS, Ivory, 1.82 in W x 1.62 in D x 4.15 in H Dimensions

Manufacturer PN: WS2000I

UPC:  78358525630

Kendall Electric Inc PN: 3358125

Invoice Description:

WS2000I HUBBELL OCC/VAC SENSOR,PIR,120/277V,IV 78358525630


SPEC SHEET

▸ See All in Wall Mount Occupancy Sensors


How Can We Make This Page Better?

Wiring Device-Kellems H-MOSS® WS2000I 3-Way Adjustable Occupancy Sensor Switch, 120/277 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, 180 deg Viewing, Threaded Mount

Log In for Pricing and Availability




Description

Hubbell® WS/ATP series wall switches combine PIR sensing technology, photocell control and Hubbell® patented three wire method to provide the perfect light switch replacement solution. These sensors do not require a neutral connection and they have no minimum load requirements. The WS series has manual timer adjustment while the ATP series incorporates Hubbell® patented adaptive technology to automatically set timing and eliminate manual adjustments. The sensors come supplied with color matched faceplates. Manual-ON versions are available for enhanced savings. Four wire models support installations that require a neutral connection.
Wiring Device-Kellems H-MOSS® Occupancy Sensor Switch, 3-Way Adjustable, Series: WS Series, 120/277 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, 180 deg Viewing, 20 s to 30 min Time Delay, Incandescent Lamp, 60 Hz Response, Screw Terminal Connection, Automatic/Manual On Control Output, Threaded Mounting, 32 to 122 deg F, ABS, Ivory, 1.82 in W x 1.62 in D x 4.15 in H Dimensions

Specifications

 Application Private Offices, Small Restrooms, Break Areas, Classrooms, Closets, Storage Areas and Indoor Dry Environment, LED and CFL Applications
 Brand Name Hubbell Premise Wiring
 Color Ivory
 Connection Type Screw Terminal
 Control Output Automatic/Manual On
 Coverage 1000 sq-ft
 Dimensions 1.82 in W x 1.62 in D x 4.15 in H
 Includes Wallplate
 Lamp Type Incandescent
 Manufacturer Part Number WS2000I
 Material ABS
 Mounting Type Threaded
 Response Frequency 60 Hz
 Sensor Type Passive Infrared
 Series WS Series
 Standards/Approvals California Title 24 Compliant|cULus Listed|UL 773A|UL 94 V-0 Flammability Rated
 Temperature Rating 32 to 122 deg F
 Time Delay 20 s to 30 min
 Type 3-Way Adjustable
 Video Links
 Viewing Angle 180 deg
 Voltage Rating 120/277 VAC

Features

▪ Designed for use on 120 or 277 VAC circuits, no neutral required, fast retrofits
▪ Built-in photocell prevents lights from turning On with sufficient natural light
▪ Polyethylene lens
▪ 42 to 54 in above floor mounting height
▪ Steel mounting strap
▪ Red LED sensing indicator
▪ 3-Way capable
