Hubbell
WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622

Mouse over image to zoom, click to enlarge

  • WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622
  • WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622
  • WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622
  • WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622
  • WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622

Description: Wiring Device-Kellems, WS1000W, Occupancy Sensor Switch, 1-Circuit Adjustable, Series: WS Series, 120 VAC, 500 W Power, Passive Infrared Sensor, 1000 sq-ft Coverage, 20 s to 30 min Time Delay, Incandescent Lamp, 60 Hz Response, Wire Lead Connection, Automatic/Manual On Control Output, Threaded Mounting, 32 to 122 deg F, ABS, White, 1.82 in W x 0.61 in D x 4.15 in H Dimensions

Manufacturer PN: WS1000W

UPC:  78358525622

Kendall Electric Inc PN: 3459401

Invoice Description:

WS1000W HUBBELL OCC SENSOR,PIR,120V 500W,WH 78358525622


SPEC SHEET

▸ See All in Wall Mount Occupancy Sensors


How Can We Make This Page Better?

Wiring Device-Kellems WS1000W WS Series 1-Circuit Adjustable Occupancy Sensor Switch, 120 VAC, Passive Infrared Sensor, 1000 sq-ft Coverage, Threaded Mounting

Log In for Pricing and Availability




Description

Hubbell® WS/ATP series wall switches combine PIR sensing technology, photocell control and Hubbell® patented three wire method to provide the perfect light switch replacement solution. These sensors do not require a neutral connection and they have no minimum load requirements. The WS series has manual timer adjustment while the ATP series incorporates Hubbell® patented adaptive technology to automatically set timing and eliminate manual adjustments. The sensors come supplied with color matched faceplates. Manual-ON versions are available for enhanced savings. Four wire models support installations that require a neutral connection.
Wiring Device-Kellems, WS1000W, Occupancy Sensor Switch, 1-Circuit Adjustable, Series: WS Series, 120 VAC, 500 W Power, Passive Infrared Sensor, 1000 sq-ft Coverage, 20 s to 30 min Time Delay, Incandescent Lamp, 60 Hz Response, Wire Lead Connection, Automatic/Manual On Control Output, Threaded Mounting, 32 to 122 deg F, ABS, White, 1.82 in W x 0.61 in D x 4.15 in H Dimensions

Specifications

 Application Circuit Control, Private Offices, Small Restrooms, Break Areas, Classrooms, Closets Storage Areas, Indoor Dry Environment, LED and CFL Applications
 Brand Name Hubbell Premise Wiring
 Color White
 Connection Type Wire Lead
 Control Output Automatic/Manual On
 Coverage 1000 sq-ft
 Dimensions 1.82 in W x 0.61 in D x 4.15 in H
 Includes Nylon Wallplate
 Lamp Type Incandescent
 Manufacturer Part Number WS1000W
 Material ABS
 Mounting Type Threaded
 Power Rating 500 W
 Response Frequency 60 Hz
 Sensor Type Passive Infrared
 Series WS Series
 Standards/Approvals CEC Title 24 Compliant|CSA Certified|cULus Listed|UL Listed to UL 773A|UL94 V-0 Flammability Rating
 Temperature Rating 32 to 122 deg F
 Time Delay 20 s to 30 min
 Type 1-Circuit Adjustable
 Video Links
 Voltage Rating 120 VAC

Features

▪ Polyethylene lens
▪ Tamper resistant lens
▪ Metal mounting strap
▪ 42 to 54 in above floor mounting height
▪ Red LED sensing indicator
▪ 20 to 90 Percent non-condensing relative humidity
▪ Designed for use on 120 VAC circuits, no neutral required, fast retrofits
▪ LED lighting compatible
