Hubbell
WIRING HBL20GB306IVTR PLUGTRAK TAMPER RESIST 15A 3FT STEEL IV

Mouse over image to zoom, click to enlarge

  • WIRING HBL20GB306IVTR PLUGTRAK TAMPER RESIST 15A 3FT STEEL IV
  • WIRING HBL20GB306IVTR PLUGTRAK TAMPER RESIST 15A 3FT STEEL IV
  • WIRING HBL20GB306IVTR PLUGTRAK TAMPER RESIST 15A 3FT STEEL IV

Description: Hubbell Wiring Device-Kellems, HBL20GB306IVTR, Fully Insulated Tamper Resistant Pre-Wired Raceway, 3 ft Length, 1-1/2 in Width, 1 in Height, 125 V, 12 AWG THHN Stranded Cable, 6 Outlets, 6 in Outlet Center Distance, Single Receptacle/Circuit Outlet, Outlet Configuration: (6) Tamper Resistant Receptacle, (1) Circuit, 1875 W, 15 A Outlet, Hole Mounting, Steel, Ivory

Manufacturer PN: HBL20GB306IVTR

UPC:  78358545589

Kendall Electric Inc PN: 4404210

Invoice Description:

WIRING HBL20GB306IVTR PLUGTRAK TAMPER RESIST 15A 3FT STEEL IV


SPEC SHEET

▸ See All in Prewired Raceways


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems HBL20GB306IVTR Fully Insulated Tamper Resistant Pre-Wired Raceway, 3 ft L x 1-1/2 in W x 1 in H, Steel

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Tamper-Resistant (TR) PlugTrak® is an ideal solution when additional outlets are required in kitchens, workshops, laboratories and many other areas of a home, school or commercial building. TR PlugTrak® complies with NEC 406.12 which calls for Tamper-Resistant Receptacles in Dwelling Units. Hubbell® offers a broad range of Tamper-Resistant PlugTrak®. Available in aluminum, steel and non-metallic versions, each material is offered in 15 A and 20 A configurations, with a variety of lengths and receptacle spacing options. Hubbell® fts 20 A PlugTrak® features the same compact housing as our 15 A product. A wide assortment of accessories allow for easy installation in every application.
Hubbell Wiring Device-Kellems, HBL20GB306IVTR, Fully Insulated Tamper Resistant Pre-Wired Raceway, 3 ft Length, 1-1/2 in Width, 1 in Height, 125 V, 12 AWG THHN Stranded Cable, 6 Outlets, 6 in Outlet Center Distance, Single Receptacle/Circuit Outlet, Outlet Configuration: (6) Tamper Resistant Receptacle, (1) Circuit, 1875 W, 15 A Outlet, Hole Mounting, Steel, Ivory

Specifications

 Application Permanently Installed Applications
 Brand Name Hubbell Premise Wiring
 Cable Type 12 AWG THHN Stranded
 Color Ivory
 Height 1 in
 Includes Receptacle
 Length 3 ft
 Manufacturer Part Number HBL20GB306IVTR
 Material Steel
 Mounting Type Hole
 Number of Outlets 6
 Outlet Center Distance 6 in
 Outlet Configuration (6) Tamper Resistant Receptacle, (1) Circuit
 Outlet Rating 1875 W, 15 A
 Outlet Type Single Receptacle/Circuit
 PART NUMBER KEYWORDS HBL20GB306IVTR ; 11910710 ; 13690044 ; 783585455891 ; 78358545589 ; 00783585455891 ; 0783585455891
 Standards/Approvals UL 5|CSA C22.2 No. 2, File No. E253976/E253830/E253833
 Type 1-Phase Fully Insulated Tamper Resistant
 Video Links
 Voltage Rating 125 V
 Width 1-1/2 in

Features

▪ Multiple spacing configurations
▪ Insulation displacement wiring provides superior wire retention
