Schneider Electric
VZ18 SQD EXTENSION KIT

Mouse over image to zoom, click to enlarge

  • VZ18 SQD EXTENSION KIT
  • VZ18 SQD EXTENSION KIT

Description: Square D™, VZ18, Shaft Extension Kit, Series: VZ Series, For Use With: Vario™ V02 to V2, V3, V4, V5, V6 Manual Motor Control Switch, Specifications: 320 mm Size, Front Mount, Direct Connection, 0.31 in W x 0.31 in H Dimensions

Manufacturer PN: VZ18

UPC:  38911055221

Kendall Electric Inc PN: 3959733

Invoice Description:

VZ18 SQD EXTENSION KIT


SPEC SHEET

▸ See All in Disconnect Switch Shaft Hardware


How Can We Make This Page Better?

Square D™ VZ18 VZ Series Shaft Extension Kit, For Use With Vario™ V02 to V2, V3, V4, V5, V6 Manual Motor Control Switch, 320 mm Size, Front Mount, Direct Connection

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

TeSys Vario shaft extension, for TeSys Vario switch bodies V3 to V6. It allows the operation of a switch body located on the back of enclosure with a door-mounted handle. Possible distance between back of enclosure and door 300-320mm for V3-V4 and 330-350mm for V5-V6.
Square D™, VZ18, Shaft Extension Kit, Series: VZ Series, For Use With: Vario™ V02 to V2, V3, V4, V5, V6 Manual Motor Control Switch, Specifications: 320 mm Size, Front Mount, Direct Connection, 0.31 in W x 0.31 in H Dimensions

Specifications

 Application For door interlocking function applications
 Brand Name Square D
 Dimensions 0.31 in W x 0.31 in H
 Manufacturer Part Number VZ18
 PART NUMBER KEYWORDS VZ18 ; 8088568 ; 785901552215 ; 78590155221 ; 03389110552218 ; 3389110552218
 Series VZ Series
 Specifications 320 mm Size, Front Mount, Direct Connection
 Standards/Approvals RoHS Compliant|ECCN: EAR99|UL Listed|IEC Certified|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
 Suitable For Use With Vario™ V02 to V2, V3, V4, V5, V6 Manual Motor Control Switch
 Video Links

Features

▪ Easy for operation on the back of enclosure with a door-mounted handle
▪ It leaves sufficient and suitable distance between the door and the switch
