Emerson Electric
VMV5LCG5BU APPLETON CNT LED 5000LM, CW, CG, 120-277

Mouse over image to zoom, click to enlarge

Description: Appleton® LED Luminaire, Enclosed Gasketed, Series: Contender™, 120 to 277 V AC/125 to 300 V DC, 1300 mA, LED Lamp, 48 W Lamp, 200000 hr Average Life, Cool White Light, 5000 K Color Temperature, >70 CRI, Glass Globe Lens, 5500 Lumens, NEMA 3R/4/4X/5/IP66/IP67 Enclosure, Pendant/Flexible Pendant/Ceiling/Wall/Quad/25 deg Stanchion/Straight Stanchion Mounting, Cast Copper-Free Aluminum Housing Material, Epoxy Powder Coated Housing Finish, 5.76 x 11.56 in Dimensions

Manufacturer PN: VMV5LCG5BU

UPC:  78138122823

Kendall Electric Inc PN: 3823551

Invoice Description:

VMV5LCG5BU APPLETON CNT LED 5000LM, CW, CG, 120-277


SPEC SHEET

How Can We Make This Page Better?

Appleton® VMV5LCG5BU Contender™ Enclosed Gasketed LED Luminaire, LED Lamp, 120 to 277 V AC/125 to 300 V DC, Epoxy Powder Coated Housing

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Contender™ LED luminaires deliver exceptional efficiency, performance and advanced engineering. The compact light weight low profile design is suited for low mounting heights. With four different field replaceable globe options (clear and diffused polycarbonate, clear glass, or prismatic glass refractor) it can be customized to application requirements. With three light output levels, it is ideal for retrofitting HID fixtures up to 175 W. The Contender™ LED is designed to mount directly to a select offering of competitor's mounting hoods.
Appleton® LED Luminaire, Enclosed Gasketed, Series: Contender™, 120 to 277 V AC/125 to 300 V DC, 1300 mA, LED Lamp, 48 W Lamp, 200000 hr Average Life, Cool White Light, 5000 K Color Temperature, >70 CRI, Glass Globe Lens, 5500 Lumens, NEMA 3R/4/4X/5/IP66/IP67 Enclosure, Pendant/Flexible Pendant/Ceiling/Wall/Quad/25 deg Stanchion/Straight Stanchion Mounting, Cast Copper-Free Aluminum Housing Material, Epoxy Powder Coated Housing Finish, 5.76 x 11.56 in Dimensions

Specifications

 Amperage Rating 1300 mA
 Application For use in marine and hazardous and wet locations, walkways/catwalks, stairwells, grain elevators, tunnels, pipe racks, offshore rigs, vessel lighting, cooling towers and processing areas
 Average Life 200000 hr
 Brand Name Appleton
 Color Rendering Index CRI >70
 Color Temperature 5000 K
 Dimensions 5.76 x 11.56 in
 Enclosure NEMA 3R/4/4X/5/IP66/IP67
 Housing Finish Epoxy Powder Coated
 Housing Material Cast Copper-Free Aluminum
 Lamp Type LED
 Lamp Wattage 48 W
 Light Color Cool White
 Lumens 5500 Lumens
 Manufacturer Part Number VMV5LCG5BU
 Mounting Type Pendant/Flexible Pendant/Ceiling/Wall/Quad/25 deg Stanchion/Straight Stanchion
 PART NUMBER KEYWORDS VMV5LCG5BU ; 14584212 ; 781381228237 ; 78138122823 ; 00781381228237
 Series Contender™
 Standards/Approvals NEC Certified|CEC Compliant|ABS Approved|CSA Certified|UL Listed|Class I Div 2 Groups A/B/C/D/Zone 2/Group IIC/Class II/Div 1 Groups E/F/G/Zone 21/22/Group IIIC/Class II Div 2 Groups F/G/Class III
 Type Enclosed Gasketed
 Voltage Rating 120 to 277 V AC/125 to 300 V DC

Features

▪ 150 to 175 W HPS light level equivalent
▪ Enclosed and gasketed fixtures suitable for use in a wide range of industrial, chemical processing and other areas where flammable gases, vapors and combustible dusts and fibers are present including simultaneous exposure
▪ Ideal for use in areas of low clearance, low ceiling heights or where fixture weights must be minimized
▪ Typical industries include pulp and paper mills, processing plants, chemical plants, petrochemical facilities, oil refineries, drilling rigs, foundries, waste treatment, mining and steel mills
▪ Compact, light weight low profile design is suited for low mounting heights (less than 12 lb)
▪ Customize to the application requirements with four different field replaceable globe options: clear and diffused polycarbonate, clear glass, or prismatic glass refractor
▪ Three light output levels for retrofit of HID fixtures up to 175 W
▪ Standard 6 kV surge protection
▪ Heavy duty, high temperature silicone rubber gaskets
▪ Luminaire comes pre-wired with three conductors, approximately 12 in L of 14 AWG TEW wire from the IP68 watertight NPT hub at the top of the luminaire lid
