Hubbell
USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..

Mouse over image to zoom, click to enlarge

  • USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..
  • USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..
  • USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..
  • USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..
  • USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..

Description: Hubbell Wiring Device-Kellems tradeSELECT® USB Charger Receptacle, Duplex Grounding Heavy Duty Tamper-Resistant Standard, 125 V AC, 20 A, 1875 W Electrical Rating, 1 ph, 2 Pole, 3 Wires, 14 to 10 AWG Wire, Class A USB, 2 USB Quantity, 5 A, 5 VDC USB, 1.75 in W x 1.82 in D x 3.28 in H Size, Screw Terminal Connection, Commercial Grade, Composite, White, Environmental Conditions: -40 to 75 deg C Operating, NEMA 5-15R Enclosure

Manufacturer PN: USB15A5W

UPC:  88377830689

Kendall Electric Inc PN: 3835024

Invoice Description:

USB15A5W HUBBELL RCPT DUP 15A 125V 5A 5V USB PORT A WH..


SPEC SHEET

How Can We Make This Page Better?

Hubbell Wiring Device-Kellems tradeSELECT® USB15A5W Duplex Grounding Heavy Duty Tamper-Resistant Standard USB Charger Receptacle With Green LED, 125 V AC, 20 A, 1875 W, 1 Phase, 2 Poles, 3 Wires, White

Log In for Pricing and Availability




Description

Hubbell® USB chargers are available in the new Type-C port, a combination unit with type A and C and the legacy type A, all with more power. The increase in power to a 5 Amp 5 VAC USB port adds capacity so that there is always ample current to support multiple device charging. Portable mobile manufacturers are using the faster Type-C ports. More phones, tablets and other electronic devices are expected to use this new standard.
Hubbell Wiring Device-Kellems tradeSELECT® USB Charger Receptacle, Duplex Grounding Heavy Duty Tamper-Resistant Standard, 125 V AC, 20 A, 1875 W Electrical Rating, 1 ph, 2 Pole, 3 Wires, 14 to 10 AWG Wire, Class A USB, 2 USB Quantity, 5 A, 5 VDC USB, 1.75 in W x 1.82 in D x 3.28 in H Size, Screw Terminal Connection, Commercial Grade, Composite, White, Environmental Conditions: -40 to 75 deg C Operating, NEMA 5-15R Enclosure

Specifications

 Application Dry Locations, Indoor, USB Charging, Power, Commercial, Industrial, Home, Phones, Tablets and Other Electronic Device Applications
 Brand Name Hubbell Premise Wiring
 Color White
 Connection Screw Terminal
 Electrical Ratings 125 V AC, 20 A, 1875 W
 Environmental Conditions -40 to 75 deg C Operating, NEMA 5-15R Enclosure
 Grade Commercial
 Manufacturer Part Number USB15A5W
 Material Composite
 Number of Poles 2
 Number of Wires 3
 PART NUMBER KEYWORDS USB15A5W ; 13848889 ; 883778306891 ; 88377830689 ; 00883778306891
 Phase 1
 Size 1.75 in W x 1.82 in D x 3.28 in H
 Standards/Approvals cULus Listed|UL 498|1310|CSA Certified|UL94 V-2 Flammability Rating
 Type Duplex Grounding Heavy Duty Tamper-Resistant Standard
 USB Quantity 2
 USB Rating 5 A, 5 V DC
 USB Type Class A

Features

▪ High Power 5 A 5 V USB Output
▪ USB Ports Rated 10,000 Cycles
