Acuity Brands
TWH-LED-ALO-50K LITHONIA WALLPACK (CI#265A24)

Mouse over image to zoom, click to enlarge

  • TWH-LED-ALO-50K LITHONIA WALLPACK (CI#265A24)
  • TWH-LED-ALO-50K LITHONIA WALLPACK (CI#265A24)
  • TWH-LED-ALO-50K LITHONIA WALLPACK (CI#265A24)
  • TWH-LED-ALO-50K LITHONIA WALLPACK (CI#265A24)

Description: Lithonia Lighting®, TWH LED ALO 50K, Wallpack, Rectangular, Series: TWH LED, 120 to 277 V AC, 78 W Fixture, 0.3/0.36/0.41/0.7 A, LED Lamp, 100000 hr Average Life, Daylight Light, 5000 K Color Temperature, 70 CRI, Tempered Glass Lens, 9214 Lumens, Wall Mounting, Die Cast Aluminum Housing Material, Dark Bronze Housing Finish, 15-3/4 in H x 16-1/4 in W x 8 in D Dimensions

Manufacturer PN: TWHLEDALO50K

UPC:  19184835532

Kendall Electric Inc PN: 3826421

Invoice Description:

TWH-LED-ALO-50K LITHONIA WALLPACK (CI#265A24)


SPEC SHEET

▸ See All in Outdoor Wallpacks


How Can We Make This Page Better?

Lithonia Lighting® TWH LED ALO 50K TWH LED Rectangular Wallpack, LED Lamp, 78 W Fixture, 120 to 277 V AC, Dark Bronze Housing

Log In for Pricing and Availability




Description

The Lithonia Lighting TWH LED offers a classic appearance and is powered by advanced LEDs. The TWH LED luminaire is powerful yet energy efficient, capable of replacing up to a 400W metal halide luminaire while saving up to 83% in energy costs. Offering an expected service life of more than 20 years, the TWH LED eliminates frequent lamp and ballast replacements associated with traditional technologies. The TWH LED features an Adjustable Light Output (ALO) that allows the contractor to set the light output during installation to a level perfectly suited for the job site. The feature allows one luminaire to replace anywhere from 70W to all the way up to 400W metal halide luminaire.
Lithonia Lighting®, TWH LED ALO 50K, Wallpack, Rectangular, Series: TWH LED, 120 to 277 V AC, 78 W Fixture, 0.3/0.36/0.41/0.7 A, LED Lamp, 100000 hr Average Life, Daylight Light, 5000 K Color Temperature, 70 CRI, Tempered Glass Lens, 9214 Lumens, Wall Mounting, Die Cast Aluminum Housing Material, Dark Bronze Housing Finish, 15-3/4 in H x 16-1/4 in W x 8 in D Dimensions

Specifications

 Amperage Rating 0.3/0.36/0.41/0.7 A
 Application Education, Hospitality, Offices, Banks, Carports, Loading Areas, Driveways and Parking Area Applications
 Average Life 100000 hr
 Brand Name Lithonia Lighting®
 Color Rendering Index CRI 70
 Color Temperature 5000 K
 Dimensions 15-3/4 in H x 16-1/4 in W x 8 in D
 Fixture Wattage 78 W
 Housing Finish Dark Bronze
 Housing Material Die Cast Aluminum
 Lamp Type LED
 Light Color Daylight
 Lumens 9214 Lumens
 Manufacturer Part Number TWH LED ALO 50K
 Mounting Type Wall
 PART NUMBER KEYWORDS TWH LED ALO 50K ; TWHLEDALO50K ; 265A24 ; 14257265 ; 14258065 ; 191848355329 ; 19184835532 ; 00191848355329
 Series TWH LED
 Standards/Approvals UL Listed for Wet Location|DLC Listed
 Type Rectangular
 Video Links
 Voltage Rating 120 to 277 V AC

Features

▪ BATTERY BACKUP - No emergency battery back-up available in this version
▪ The Lithonia Lighting TWH LED offers a classic appearance and is powered by advanced LEDs
▪ The TWH LED luminaire is powerful yet energy efficient, capable of replacing up to a 400W metal halide luminaire while saving up to 83% in energy costs
▪ Offering an expected service life of more than 20 years, the TWH LED eliminates frequent lamp and ballast replacements associated with traditional technologies
▪ The TWH LED features an Adjustable Light Output (ALO) that allows the contractor to set the light output during installation to a level perfectly suited for the job site
▪ The feature allows one luminaire to replace anywhere from 70W to all the way up to 400W metal halide luminaire
▪ TECHNOLOGY - The ALO feature allows contractors to easily adjust to customers lighting needs allowing customers to save up to 80% in energy compared to traditional light sources
▪ VOLTAGE - 120-277V and can be mounted on any vertical surface
▪ HOURS OF LIFE - Light engine(s) consist of 72 high-efficacy LEDs mounted to metal-core circuit board and integral aluminum heat sink to maximize heat dissipation and promote long life (L93/100,000 hr at 25C)
▪ DURABILITY - Die-cast aluminum housing has an impact-resistant, tempered glass lens that is fully gasketed with the LED driver mounted to the front casting and housing is completely sealed against moisture and environmental contaminants
