Eaton
TPC-75 BUSSMANN TPC FUSE 75A

Mouse over image to zoom, click to enlarge

  • TPC-75 BUSSMANN TPC FUSE 75A
  • TPC-75 BUSSMANN TPC FUSE 75A
  • TPC-75 BUSSMANN TPC FUSE 75A
  • TPC-75 BUSSMANN TPC FUSE 75A

Description: Bussmann Telpower® Telecommunication Fuse, Compact Current Limiting, Series: TPC, Indicating/Non-Indicating: Non-Indicating, 75 A, 80 VDC, 100 kAIC Interrupt, Plug-In Terminal, Holder Mount, Square Body Type, Thermoplastic, Black, 1.824 in L X 1.846 in W Body Size

Manufacturer PN: TPC-75

UPC:  05171266907

Kendall Electric Inc PN: 4875200

Invoice Description:

TPC-75 BUSSMANN TPC FUSE 75A


SPEC SHEET

▸ See All in Telecommunications Fuses


How Can We Make This Page Better?

Bussmann Telpower® TPC-75 Compact Current Limiting Telecommunication Fuse, 75 A, 80 VDC, 100 kAIC Interrupt, Square Body

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann Telpower® Telecommunication Fuse, Compact Current Limiting, Series: TPC, Indicating/Non-Indicating: Non-Indicating, 75 A, 80 VDC, 100 kAIC Interrupt, Plug-In Terminal, Holder Mount, Square Body Type, Thermoplastic, Black, 1.824 in L X 1.846 in W Body Size

Specifications

 Amperage Rating 75 A
 Application IT and Data Communication, Telecommunication DC Power Circuit Protection, DC Telecommunication Circuit Breaker Applications
 Body Size 1.824 in L X 1.846 in W
 Body Type Square
 Brand Name Bussmann
 Color Black
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number TPC-75
 Material Thermoplastic
 Mounting Type Holder
 Series TPC
 Standards/Approvals CE Certified|cULus File No. E219046/E56412|UL 1801|UL 94-V-0 Flammability Rating
 Terminal Type Plug-In
 Type Compact Current Limiting
 Video Links
 Voltage Rating 80 VDC

Features

▪ Fusible solution for replacement of existing DC Telecom circuit breakers
▪ AmpColor ID™ system for easy fuse replacement
▪ Local alarm indication provided by LED on TPC fuse
