Eaton
TL480N25 CH STARTING TORQUE LIMITER, 25 AMP, 208-480VAC

Mouse over image to zoom, click to enlarge

  • TL480N25 CH STARTING TORQUE LIMITER, 25 AMP, 208-480VAC
  • TL480N25 CH STARTING TORQUE LIMITER, 25 AMP, 208-480VAC
  • TL480N25 CH STARTING TORQUE LIMITER, 25 AMP, 208-480VAC

Description: EATON Solid State Torque Limiting Controller, Series: 10250T, Specifications: 25 A, 208 to 480 V AC, 1LONC-1ECNO Contact Configuration, NEMA 3/3R/4/4X/12/13, Soft Start, 7-1/2 x 5-3/4 x 2-3/4 in Dimensions

Manufacturer PN: TL480N25

UPC:  78211481887

Kendall Electric Inc PN: 2015140

Invoice Description:

TL480N25 CH STARTING TORQUE LIMITER, 25 AMP, 208-480VAC


SPEC SHEET

▸ See All in Motor Control Miscellaneous Accessories


How Can We Make This Page Better?

EATON TL480N25 10250T Solid State Torque Limiting Controller, 25 A, 208 to 480 V AC, 1LONC-1ECNO Contact Configuration, NEMA 3/3R/4/4X/12/13, Soft Start

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

TL Torque Limiters regulate current on one of the three motor phases to control the torque being applied to the motor, allowing for smooth starting of a motor. Designed to be used with a Manual Motor Starter or a Full Voltage Starter, they provide necessary over-load protection and line isolation for the motor. These easy-to-install, compact devices are rated up to 25A, for controlled acceleration and deceleration of fractional to 15 hp/11 kW motors at 480/400 Vac.
EATON Solid State Torque Limiting Controller, Series: 10250T, Specifications: 25 A, 208 to 480 V AC, 1LONC-1ECNO Contact Configuration, NEMA 3/3R/4/4X/12/13, Soft Start, 7-1/2 x 5-3/4 x 2-3/4 in Dimensions

Specifications

 Application Commercial, Institutional Buildings and Structures Applications
 Brand Name EATON
 Dimensions 7-1/2 x 5-3/4 x 2-3/4 in
 Manufacturer Part Number TL480N25
 PART NUMBER KEYWORDS TL480N25 ; 7417431 ; 782114818879 ; 78211481887 ; 00782114818879
 Series 10250T
 Specifications 25 A, 208 to 480 V AC, 1LONC-1ECNO Contact Configuration, NEMA 3/3R/4/4X/12/13, Soft Start
 Standards/Approvals CSA Certified,UL Listed

Features

▪ 0.5 to 5 s adjustable ramp times
▪ 0 to 85 % adjustable initial torque control
▪ IP20 finger protection and unlimited number of START/STOP operations per hour
