TCF300 BUSSMANN CUBEFUSE 300 AMP

Mouse over image to zoom, click to enlarge

  • TCF300 BUSSMANN CUBEFUSE 300 AMP
  • TCF300 BUSSMANN CUBEFUSE 300 AMP

Description: EATON Bussmann Low-Peak™ CUBEFuse™ Fuse, Indicating Time Delay, Series: TCF, 300 A, 600 V, 200 kA Interrupt, Class: CF, 10 s Response, Blade Terminal, Holder Mount, Square Body Type, Dual Element, Glass Filled Polyethersulfone, 3.46 in W x 1.69 in D x 4.25 in H Body Size

Manufacturer PN: TCF300

UPC:  05171269783

Kendall Electric Inc PN: 3899660

Invoice Description:

TCF300 BUSSMANN CUBEFUSE 300 AMP


SPEC SHEET

How Can We Make This Page Better?

EATON Bussmann Low-Peak™ CUBEFuse™ TCF300 Indicating Time Delay Fuse, 300 A, 600 V, 200 kA Interrupt, Class: CF, Square Body

Log In for Pricing and Availability




Description

The revolutionary BussmannTM series Low-PeakTM CUBEFuseTM delivers the smallest footprint compared to any Class CC, J or RK fuse solution — requiring up to 70 less space when combined with its unique fuse holder or UL 98 Listed Compact Circuit Protector switch. Freeing up space is powerful. And the CUBEFuse does just that, while packing up to a 300 kA interrupting rating and enabling higher equipment short-circuit current rating (SCCR). Available from 1 to 400 amps.
EATON Bussmann Low-Peak™ CUBEFuse™ Fuse, Indicating Time Delay, Series: TCF, 300 A, 600 V, 200 kA Interrupt, Class: CF, 10 s Response, Blade Terminal, Holder Mount, Square Body Type, Dual Element, Glass Filled Polyethersulfone, 3.46 in W x 1.69 in D x 4.25 in H Body Size

Specifications

 Amperage Rating 300 A
 Application Commercial/Institutional Buildings/structures, Power Distribution and Control, Electrical Panelboards, Machinery Disconnects, Finger Safe Systems, Industrial Control and Panel Applications, Stationary Machinery and Equipment Outside Factory
 Body Size 3.46 in W x 1.69 in D x 4.25 in H
 Body Type Square
 Brand Name Bussmann
 Class CF
 Element Dual
 Manufacturer Part Number TCF300
 Material Glass Filled Polyethersulfone
 Mounting Type Holder
 PART NUMBER KEYWORDS TCF300 ; 14584318 ; 051712697835 ; 51712697835 ; 05171269783 ; 00051712697835
 Response Time 10 s
 Series TCF
 Standards/Approvals UL Listed,RoHS Compliant
 Terminal Type Blade
 Type Indicating Time Delay
 Video Links
 Voltage Rating 600 V

Features

▪ Low let through currents under fault conditions
▪ Provides type 2 "no damage" in protection for IEC® motors starters when properly sized
▪ Easy selective co-ordination with any other Bussmann series Low-Peak™ class CC, J, L or RK1 fuse with simple 2:1 amp ratio between upstream and downstream fuses
▪ 200 kA rms symmetrical, 100 kA DC interrupting rating
▪ The worlds first finger safe industrial fuse system
▪ Smallest installed footprint of any UL Class CC, J, or R fuse solution
▪ UL class CF with Class J time delay electrical performance
▪ The indicating version features easyID™ open fuse technology for faster troubleshooting and reduced downtime
▪ Faster response to damaging faults reduces destructive thermal and magnetic forces
▪ True dual-element fuse construction with a minimum of 10 sec time delay at 500% of rating
▪ Long time delay minimizes nuisance circuit openings due to temporary overloads and transient surges
▪ Up to 300 kA interrupting rating safely interrupts virtually any fault
▪ Robust cycling and inrush current withstand
