Honeywell

T775-SENS-OAT HONEYWEL OUTDOOR AIR TEMPERATURE SENSOR FOR T775 SERIES 2000, 1097 OHMS PTC @ 77F (25C).

Mouse over image to zoom, click to enlarge

Description: Honeywell Temperature Sensor, -40 to 158 deg F, 1097 Ohm, 8-5/16 in H x 3-5/8 in W x 2-1/4 in D, Domestic

Manufacturer PN: T775-SENS-OAT/U

UPC: 08526731312

Kendall Electric Inc PN: 2933897

Invoice Description:

T775-SENS-OAT HONEYWEL OUTDOOR AIR TEMPERATURE SENSOR FOR T775 SERIES 2000, 1097 OHMS PTC @ 77F (25C).

SPEC SHEET

How Can We Make This Page Better?

Honeywell T775-SENS-OAT/U Temperature Sensor, -40 to 158 deg F, 1097 Ohm, Domestic

Note: Lead times are estimates only

Description Specifications Features Resources

Description

A family of general use, simple to use, broadly featured electronic temperature and universal controllers for use in HVAC, agricultural, and industrial applications.

Honeywell Temperature Sensor, -40 to 158 deg F, 1097 Ohm, 8-5/16 in H x 3-5/8 in W x 2-1/4 in D, Domestic

Specifications

Brand Name	Honeywell
Dimensions	8-5/16 in H x 3-5/8 in W x 2-1/4 in D
Domestic or Import	Domestic
Manufacturer Part Number	T775-SENS-OAT/U
PART NUMBER KEYWORDS	T775-SENS-OAT/U ; T775SENSOATU ; 085267313124 ; 08526731312 ; 85267313124
Sensor	1097 Ohm
Temperature Rating	-40 to 158 deg F

Features

▪ Two year warranty

▪ Used with T775 series 2000

▪ 1097 ohm at 77 deg F PTC

▪ Use the T775-SENS-OAT to measure outside air temperature

▪ Some typical applications for the 50021579-001 and T775-SENSWT/WR sensors include monitoring return air, discharge air and mixed air temperatures

▪ Sensors have fast response time and highly accurate

▪ Sensors have 1/2 in stainless steel probe with a thermally conductive epoxy

▪ Sensors are 1,097 ohm PTC at 77XF (25C)

▪ The 50021579-001 is a standard temperature sensor for indoor applications

▪ The T775-SENS-WR is a water resistant sensor with 5 ft leads

▪ The T775-SENS-WT is a water tight sensor with 6 ft leads

▪ The T775-SENS-OAT is for sensing outdoor air temperature and is housed in a weatherproof case for outdoor use (knockouts allow for 1/2 in conduit connection)
