Emerson Electric
STC-DRS-036 SOLA 36V SGL RAIL

Mouse over image to zoom, click to enlarge

Description: SolaHD Edco™ Surge Protection Device, Series: STC-DRS, 150 mA at 24 V DC Electrical Rating, 10 kA Peak Surge Current, <1 ns Response, DIN Rail Mounting

Manufacturer PN: STC-DRS-036

UPC:  78347270052

Kendall Electric Inc PN: 2537927

Invoice Description:

STC-DRS-036 SOLA 36V SGL RAIL


SPEC SHEET

How Can We Make This Page Better?

SolaHD Edco™ STC-DRS-036 Surge Protection Device, 150 mA at 24 V DC

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

STC-DRS Series DIN rail Surge Protection Device is a single pair surge protection module featuring three stage hybrid technology. Gas tubes and silicon avalanche components protect equipment from overvoltage transients, while sneak currents are mitigated with resettable fuses (PTCs). These fuses are designed to increase resistance by several orders of magnitude when an over-current exceeds safe levels, automatically resuming normal operation when the over-current is removed.
SolaHD Edco™ Surge Protection Device, Series: STC-DRS, 150 mA at 24 V DC Electrical Rating, 10 kA Peak Surge Current, <1 ns Response, DIN Rail Mounting

Specifications

 Application For industrial, machine control, automation process control, material handling, packaging equipment
 Brand Name SolaHD
 Electrical Ratings 150 mA at 24 V DC
 Manufacturer Part Number STC-DRS-036
 Mounting Type DIN Rail
 PART NUMBER KEYWORDS STC-DRS-036 ; STCDRS036 ; 9749235 ; 783472700523 ; 78347270052 ; 00783472700523
 Peak Surge Current 10 kA
 Response Time <1 ns
 Series STC-DRS
 Standards/Approvals RoHS Compliant|cUL Listed|CSA-C22.2|CE Certified|UL 508|60950-1 Listed

Features

▪ Low voltage data surge protection
▪ 3-stage hybrid protection
▪ Sneak or fault current protection with resettable fuses (%)
▪ Low profile packaging
▪ Easy installation
▪ Fast response time
