Schneider Electric
  • SN20A SQD NEUTRAL ASSY INSULATED
  • SN20A SQD NEUTRAL ASSY INSULATED
  • SN20A SQD NEUTRAL ASSY INSULATED
  • SN20A SQD NEUTRAL ASSY INSULATED
  • SN20A SQD NEUTRAL ASSY INSULATED
  • SN20A SQD NEUTRAL ASSY INSULATED

Description: Square D™ Solid Neutral Assembly, Groundable Insulated, For Use With: Heavy Duty Safety Switch, Specifications: 240/600 V AC, 200 A, 1/0 AWG to 250 kcmil Aluminum/Copper

Manufacturer PN: SN20A

UPC:  78590133160

Kendall Electric Inc PN: 3960099

Invoice Description:

SN20A SQD NEUTRAL ASSY INSULATED


SPEC SHEET

▸ See All in Switch Ground & Neutral Components


How Can We Make This Page Better?

Square D™ SN20A Groundable Insulated Solid Neutral Assembly, For Use With Heavy Duty Safety Switch, 240/600 V AC, 200 A, 1/0 AWG to 250 kcmil Aluminum/Copper

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

Schneider Electric's Square D heavy duty safety switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock, and a color coded indicator handle. They also come with many field installable or factory installed accessories. This solid neutral assembly is insulated and groundable. It has one terminal in and one terminal out, with an additional grounding terminal. Each main terminal accepts 6 AWG to 250kcmil, and the ground terminal accepts 14 AWG to 10 AWG. This accessory complies with UL and CSA standards.
Square D™ Solid Neutral Assembly, Groundable Insulated, For Use With: Heavy Duty Safety Switch, Specifications: 240/600 V AC, 200 A, 1/0 AWG to 250 kcmil Aluminum/Copper

Specifications

 Brand Name Square D
 Manufacturer Part Number SN20A
 PART NUMBER KEYWORDS SN20A ; 8145219 ; 785901331605 ; 78590133160 ; 00785901331605 ; 0785901331605
 Specifications 240/600 V AC, 200 A, 1/0 AWG to 250 kcmil Aluminum/Copper
 Standards/Approvals UL Listed
 Suitable For Use With Heavy Duty Safety Switch
 Type Groundable Insulated
 Video Links

Features

▪ Available for factory or field installation
