Bellofram Group of Companies
SLA-440-ALE MARSH ATC 480V PHASE LOSS MONITOR E-MECH DPDT C-RTG:3A C-VLT:430-480AC V-RTG:600AC S-MT

Mouse over image to zoom, click to enlarge

Description: MARSH BELLOFRAM® Phase Monitoring Relay, 3-Phase, Series: SLA, 430 to 480 V AC, 3 A, DPDT Contact Configuration, Surface Mounting, 4 in L x 4 in W x 3.63 in H Dimensions

Manufacturer PN: SLA-440-ALE

Kendall Electric Inc PN: 131587

Invoice Description:

SLA-440-ALE MARSH ATC 480V PHASE LOSS MONITOR E-MECH DPDT C-RTG:3A C-VLT:430-480AC V-RTG:600AC S-MT

▸ See All in Phase Monitoring Relays


How Can We Make This Page Better?

MARSH BELLOFRAM® SLA440ALE 3-Phase Phase Monitoring Relay, 430 to 480 V AC, 3 A, DPDT Contact

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The SLA Series Three-Phase Monitoring Relay from ATC Diversified Electronics is designed to provide cost-effective protection against from phase loss, under voltage, and phase reversal conditions that can contribute to premature motor or equipment failure and downtime.It is designed for use with three-phase systems (Delta and Wye), such as those typically found in motor control centers or other critical motor and pump monitoring applications.
MARSH BELLOFRAM® Phase Monitoring Relay, 3-Phase, Series: SLA, 430 to 480 V AC, 3 A, DPDT Contact Configuration, Surface Mounting, 4 in L x 4 in W x 3.63 in H Dimensions

Specifications

 Amperage Rating 3 A
 Application For critical motor and pump monitoring, water and wastewater plants, sewage plants, booster stations, grinders, irrigation equipment, petrochemical, machine tool, conveyors, hvac/r elevators/escalators, utilities, processing equipment, agricultural machinery and equipment, renewable energy, wind power turbine monitoring
 Brand Name MARSH BELLOFRAM®
 Contact Configuration DPDT
 Dimensions 4 in L x 4 in W x 3.63 in H
 Manufacturer Part Number SLA440ALE
 Mounting Type Surface
 PART NUMBER KEYWORDS SLA440ALE
 Series SLA
 Standards/Approvals cULus Listed|CSA Certified
 Type 3-Phase
 Voltage Rating 430 to 480 V AC

Features

▪ Monitors up to 480 VAC
▪ Protects 3-phase equipment from, phase loss, under voltage, phase reversal, delta or wye systems
▪ Fixed, lock shaft, or screwdriver adjustment
▪ Auto reset
▪ 0 to 55 deg C operating temperature
▪ 3 A at 600 VAC resistive contact rating
▪ 360 VA inductive contact rating
