| ▪ Tapered back wire openings handle multiple wire sizes and types for applications up to 10 AWG solid or stranded wire |
| ▪ When downstream receptacles are wired from load side, a 20 A feed-through rating offers full protection |
| ▪ Test and reset buttons are color matched to provide superior aesthetics |
| ▪ Longer, wider bridge strap provides 40% more contact area with wallboard, virtually eliminating floating installations |
| ▪ Exclusive built-in wire stripper provides fast stripping of wire without tools |
| ▪ Line-load miswiring protection: GFCIs will not provide power downstream when wired incorrectly |
| ▪ Tri-combo head terminal and mounting screws |
| ▪ Visual indicator lights give quick notification of a tripped or end of life condition |
| ▪ Automatically self-tests periodically to ensure GFCI protection |
| ▪ Rugged construction provides unsurpassed chemical and impact-resistant |
| ▪ Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used |
| ▪ Ground termination with back wire clamp provides secure wiring and reduces installation time |
| ▪ Line side terminals are backed out and staked for fast installation |
| ▪ Horizontal test/reset button alignment provides larger unobstructed area |
| ▪ Meets and exceeds 10 kA short circuit testing and UL 943 safety standards |
| ▪ Performs periodic self-tests to ensure integrity of GFCI protection if no ground fault protection is detected, the device will trip, will not reset and the status indicator light will glow amber |
