Resideo Technologies
SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ

Mouse over image to zoom, click to enlarge

  • SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ
  • SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ
  • SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ
  • SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ
  • SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ

Description: BRK® Smoke and Carbon Monoxide Alarm, Combination, (2) 1.5 V DC AA Batteries Power Source, Electrochemical/Photoelectric Sensor, Alarm: Audible Alarm, Up to 18 Units Interconnection, 85 dB Alert, 10 to 95 % Humidity, Audible Alarm/LED Display, Quick-Connect Wiring, 40 to 100 deg F Operating, White, 5 in Dia x 2 in H Dimensions

Manufacturer PN: SC7010B

UPC:  02905400228

Kendall Electric Inc PN: 2711275

Invoice Description:

SC7010B BRK COMBO SMOKE/CARBON MONOXIDE ALMS AC 120V INTERCONNECTABLE PHOTO/ELECTROCHEMICAL ZZZZ


SPEC SHEET

▸ See All in Smoke & CO Combination Detector & Alarms


How Can We Make This Page Better?

BRK® SC7010B Combination Smoke and Carbon Monoxide Alarm, Electrochemical/Photoelectric Sensor, (2) 1.5 V DC AA Batteries, Audible Alarm/LED Display, 85 dB

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The BRK® model no. SC7010B is a wire-in, 120 VAC 60 Hz single and multiple station combination smoke and carbon monoxide alarm specifically designed for residential and institutional applications including sleeping rooms of hospitals, hotels, motels, dormitories and other multi-family dwellings as defined in standard NFPA 101. Model SC7010B complies with UL217 and UL2034, CSFM, NFPA 72 and NFPA 720, HUD, FHA and other agencies that model their codes after the above agencies. It meets building codes where AC/DC photoelectric smoke and carbon monoxide alarms are required. The BRK® SC7010B is a state-of the art hardwired with battery backup smoke/CO combo alarm that features a photoelectric smoke sensing chamber, an electrochemical CO sensor and an end of life signal. The spread spectrum horn tone has a lower and varying frequency that makes it easier for the elderly with normal age related hearing loss to hear the horn. This alarm features two latching features and two silence features. Alarm latch easily identifies initiating alarm even after alarm condition has subsided. Low battery latch identifies which unit is in low battery condition by blinking the green power light. Low battery silence temporarily silence the low battery chirp for up to eight hours. Silence alarm for several minutes. Other features include an 85 dB horn, single button test/silence, an easy access battery drawer and dust cover. Optipath 360 technology exclusive patented technology provides 360 deg of direct access to the smoke sensor. 2- locking features are provided to prevent battery theft and/or theft of the unit. Connection to AC power is made with a quick connect wiring harness. Installation is quick, easy and cost effective.
BRK® Smoke and Carbon Monoxide Alarm, Combination, (2) 1.5 V DC AA Batteries Power Source, Electrochemical/Photoelectric Sensor, Alarm: Audible Alarm, Up to 18 Units Interconnection, 85 dB Alert, 10 to 95 % Humidity, Audible Alarm/LED Display, Quick-Connect Wiring, 40 to 100 deg F Operating, White, 5 in Dia x 2 in H Dimensions

Specifications

 Alarm Type Audible Alarm
 Application For residential and institutional applications
 Audible Alert 85 dB
 Brand Name BRK®
 Color White
 Dimensions 5 in Dia x 2 in H
 Humidity Rating 10 to 95 %
 Interconnection Capability Up to 18 Units
 Manufacturer Part Number SC7010B
 Operating Temperature 40 to 100 deg F
 PART NUMBER KEYWORDS SC7010B ; ; 029054022806 ; 29054022806 ; 02905402280 ; 00029054022806
 Power Source (2) 1.5 V DC AA Batteries
 Sensor Type Electrochemical/Photoelectric
 Standards/Approvals UL 217|UL 2034|ARRA Compliant|Buy American Act Compliant
 Type Combination
 Wiring Type Quick-Connect

Features

▪ Perfect mount allows for easy alignment of alarm
▪ Spread spectrum horn tone lower and varying frequency makes it easier for the elderly with normal aged related hearing loss to hear the horn
▪ Alarm latch remembers which unit initiated an alarm, low battery latch to visually identifies unit in low battery condition
▪ Dust cover
▪ Constant green LED AC power, intermittent green LED DC power
▪ Red LED flashes every 5 s after local alarm latching alarm
▪ Power led flashes green on for 2 s, off for 2 s low battery latch
▪ Two silence features - can silence the low-battery chirp for up to eight hours or temporarily silence an unwanted nuisance alarm
▪ Optipath 360 Technology - patented technology provides 360 degrees of direct access to the smoke sensor

Resources

 Catalog Page
 Product Data Sheet
