Description: Square D™ Homeline™ Combination Service Entrance Meter Main, All-in-One 30-Space 42-Circuit, 200 A, 1 ph, Overhead/Underground Feed, 14 to 2/0 AWG Wire, A-L Hub, Ringed Cover, Plug-On Neutral Terminal, Flush Mounting, 16.8 in W x 3.4 in D x 39.8 in H Dimensions

Manufacturer PN: SC3042M225PF

UPC:  78590110954

Kendall Electric Inc PN: 4370221

Invoice Description:

SC3042M225PF SQD ALL-IN-ONE RING


SPEC SHEET

▸ See All in Meter Socket Meter Main Combinations


How Can We Make This Page Better?

Square D™ Homeline™ SC3042M225PF All-in-One 30-Space 42-Circuit Combination Service Entrance Meter Main, 200 A, 1 ph

Log In for Pricing and Availability

Note: Lead times are estimates only




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

The Square D® Homeline® Load Centers and Homeline Solar Ready PoN CSEDs, SC3042M225PF, provides metered service and a main circuit breaker and 16 full branch spaces up to 24 circuits using tandems. All-In-Ones are UL listed, suitable only for use as service equipment. This device meets EUSERC standards, Federal Specification W-P-115c as Type 1, Class 2.Suitable for OH service with addition of tunnel kit (SCTKP20).
Square D™ Homeline™ Combination Service Entrance Meter Main, All-in-One 30-Space 42-Circuit, 200 A, 1 ph, Overhead/Underground Feed, 14 to 2/0 AWG Wire, A-L Hub, Ringed Cover, Plug-On Neutral Terminal, Flush Mounting, 16.8 in W x 3.4 in D x 39.8 in H Dimensions

Specifications

 Amperage Rating 200 A
 Brand Name Square D
 Cover Type Ringed
 Dimensions 16.8 in W x 3.4 in D x 39.8 in H
 Feed Type Overhead/Underground
 Hub Type A-L
 Manufacturer Part Number SC3042M225PF
 Mounting Type Flush
 Phase 1
 Standards/Approvals REACH Compliant|RoHS Compliant|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
 Terminal Type Plug-On Neutral
 Type All-in-One 30-Space 42-Circuit
