Lutron Electronics
  • SC-4PS-TP LUT SATIN COLOR 4-WAY SWITCH 02755749523
  • SC-4PS-TP LUT SATIN COLOR 4-WAY SWITCH 02755749523
  • SC-4PS-TP LUT SATIN COLOR 4-WAY SWITCH 02755749523

Description: Lutron®, SC-4PS-TP, Paddle Switch, 4-Way Designer Style, Series: Diva® Satin Colors®, 120/277 V AC, 15 A Electrical Rating, 60 Hz Frequency, Paddle Actuator, ON/OFF Switch Function, 4-Way Operational Mode, Back Wiring Connection, Wall Mounting, Screw Terminal, Metal/Plastic, Taupe, Environmental Conditions: 0 to 40 deg C Operating Temperature, 0 to 90% Non-Condensing Relative Humidity, 4.69 in H x 2.94 in W x 1.31 in D Dimensions

Manufacturer PN: SC-4PS-TP

UPC:  02755749523

Kendall Electric Inc PN: 2112027

Invoice Description:

SC-4PS-TP LUT SATIN COLOR 4-WAY SWITCH 02755749523


SPEC SHEET

▸ See All in Paddle Switches


How Can We Make This Page Better?

Lutron® SC-4PS-TP Diva® Satin Colors® 4-Way Designer Style Paddle Switch, 120/277 V AC, 15 A, 60 Hz

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Simple and elegant solution designed to match your existing designer style switches and accessories. Easily turn the lights on and off with the paddle switch. While the lights are on, use the sleek slide control to adjust lights to your perfect level. The
Lutron®, SC-4PS-TP, Paddle Switch, 4-Way Designer Style, Series: Diva® Satin Colors®, 120/277 V AC, 15 A Electrical Rating, 60 Hz Frequency, Paddle Actuator, ON/OFF Switch Function, 4-Way Operational Mode, Back Wiring Connection, Wall Mounting, Screw Terminal, Metal/Plastic, Taupe, Environmental Conditions: 0 to 40 deg C Operating Temperature, 0 to 90% Non-Condensing Relative Humidity, 4.69 in H x 2.94 in W x 1.31 in D Dimensions

Specifications

 Actuator Paddle
 Application For general purpose switching of all sources and motor loads
 Brand Name Lutron®
 Color Taupe
 Connection Back Wiring
 Dimensions 4.69 in H x 2.94 in W x 1.31 in D
 Electrical Ratings 120/277 V AC, 15 A
 Environmental Conditions 0 to 40 deg C Operating Temperature, 0 to 90% Non-Condensing Relative Humidity
 Frequency Rating 60 Hz
 Manufacturer Part Number SC-4PS-TP
 Material Metal/Plastic
 Mounting Wall
 Operational Mode 4-Way
 Series Diva® Satin Colors®
 Standards/Approvals UL 20|UL 1472 Listed|CSA Certified|NOM Certified
 Switch Function ON/OFF
 Terminal Type Screw
 Type 4-Way Designer Style
 Video Links

Features

▪ Precise color matching
▪ Full family of products for most lighting sources
▪ Mechanical air gap switch to disconnect load power
▪ Electrostatic discharge tested
▪ Power-failure memory
▪ Matches existing Lutron dimmers and switches
▪ Features a large paddle switch and a small slider
▪ Standard RFI suppression
▪ Satin finish
▪ Use with any 15 A load
▪ Features intuitive paddle for general purpose on/off switching of any light or fan motor
▪ For Claro switch with locator light, see SC-4PSNL-xx (select colors available)
▪ Easy installation in any home
▪ Square law dimming
▪ No derating if ganged
▪ Large paddle switch with a captive linear slide dimmer for a standard designer wallplate opening
