Legrand
RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A

Mouse over image to zoom, click to enlarge

  • RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A
  • RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A
  • RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A
  • RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A
  • RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A

Description: Pass & Seymour® WattStopper® Dimmer Switch, 2-Wire, Series: radiant®, 120 V AC, 250/300 W Power, 60 Hz Frequency, 1 Pole, CFL/Incandescent/LED Lamp, Operation Mode: 3-Way/Preset, NEMA SSL-7A Enclosure, Ground Wire Terminal, Polycarbonate, White, 4-1/4 in H x 1-3/4 in W x 1-1/4 in D Dimensions

Manufacturer PN: RHL373PW

UPC:  78500716193

Kendall Electric Inc PN: 4774091

Invoice Description:

RHL373PW P&S RADIANT CFL/LED SP/3W 450W, W SSL7A


SPEC SHEET

▸ See All in Dimmer Switches


How Can We Make This Page Better?

Pass & Seymour® WattStopper® RHL373PW radiant® 2-Wire Dimmer Switch, 120 V AC, 1 Poles, 3-Way/Preset Operation, White

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Radiant® dimmers help save energy simply and as part of the radiant collection, now offer a better fit, form and finish. Compatible with CFL/LED dimmable bulbs (with the exception of 0 to 10 V LED drivers), these dimmers feature constant memory that returns lights to the previous level after a power failure for automatic control and convenience. Ideal for all your residential and commercial applications requiring an SSL 7A compliant solution. No neutral wire required.
Pass & Seymour® WattStopper® Dimmer Switch, 2-Wire, Series: radiant®, 120 V AC, 250/300 W Power, 60 Hz Frequency, 1 Pole, CFL/Incandescent/LED Lamp, Operation Mode: 3-Way/Preset, NEMA SSL-7A Enclosure, Ground Wire Terminal, Polycarbonate, White, 4-1/4 in H x 1-3/4 in W x 1-1/4 in D Dimensions

Specifications

 Application For office, residential, multiple dwelling, hospitality/lodging, residential, commercial and indoor applications
 Brand Name Pass & Seymour®
 Color White
 Dimensions 4-1/4 in H x 1-3/4 in W x 1-1/4 in D
 Enclosure NEMA SSL-7A
 Frequency Rating 60 Hz
 Lamp Type CFL/Incandescent/LED
 Manufacturer Part Number RHL373PW
 Material Polycarbonate
 Number of Poles 1
 Operation Mode 3-Way/Preset
 Power Rating 250/300 W
 Series radiant®
 Standards/Approvals UL 1472|cULus Recognized|CSA Certified|ECCN: EAR99
 Terminal Type Ground Wire
 Type 2-Wire
 Video Links
 Voltage Rating 120 V AC

Features

▪ Designed to save energy, this dimmer is for use with LED bulbs and fixtures also designed to the SSL 7A standard for efficiency.
▪ Low-profile paddle switch offers smoother On/Off control, while a separate, ergonomic slider allows you to adjust light levels with precision
▪ Locator light illuminates when switch is off, emitting a soft glow to help you find it in the dark
▪ Constant memory features returns lights to their previous level after a power failure or outage
▪ Reducing the maximum wattage a dimmer can handle.
▪ Features durable, high-impact resistant thermoplastic construction
▪ More color options available to fit any style, including finishes to match current hardware and lighting trends
▪ Complete the look with a sleek, screwless radiant Wall Plate, and coordinate with other designer switches and outlets available from the radiant Collection
