Description: Bussmann Renewable Fuse, Non-Current Limiting Non-Time Delay Non-Indicating, Series: RES, 45 A, 600 V AC, 10 kA Interrupt, Class: H, Ferrule Terminal, Holder Mount, Cartridge Body Type, 1.06 in Dia x 5.5 in L Body Size

Manufacturer PN: RES-45

UPC: 05171211045

Kendall Electric Inc PN: 23160

Invoice Description:

RES45 BUSS 600V FUSE RFS45

SPEC SHEET

▸ See All in Renewable Fuses

How Can We Make This Page Better?

Bussmann RES-45 Non-Current Limiting Non-Time Delay Non-Indicating Renewable Fuse, 45 A, 600 V AC, 10 kA Interrupt, Class: H, Cartridge Body

Note: Lead times are estimates only

Description Specifications Features Resources

Description

Non-current limiting, renewable 250V (REN) and 600V (RES) Class H size fuses and fuse links (250V LKN and 600V LKS) for use in electrical systems where the available fault current is less than 10,000 amps and frequent outages dictate the economy of these renewable type fuses.

Bussmann Renewable Fuse, Non-Current Limiting Non-Time Delay Non-Indicating, Series: RES, 45 A, 600 V AC, 10 kA Interrupt, Class: H, Ferrule Terminal, Holder Mount, Cartridge Body Type, 1.06 in Dia x 5.5 in L Body Size

Specifications

Amperage Rating	45 A
Application	Safety and Security Systems
Body Size	1.06 in Dia x 5.5 in L
Body Type	Cartridge
Brand Name	Bussmann
Class	H
Manufacturer Part Number	RES-45
Mounting Type	Holder
Series	RES
Standards/Approvals	Not Applicable
Terminal Type	Ferrule
Type	Non-Current Limiting Non-Time Delay Non-Indicating
Video Links
Voltage Rating	600 V AC

Features

▪ Designed without multiple links for easy fuse link replacement

▪ These fuses are generally sized at the ampere rating of non-inductive circuits and 300% for motor circuits

▪ For use in electrical systems where the available fault current is less than 10 kA and frequent outages dictate the economy of these renewable type fuses
