Eaton
RD16-3-508 BUS SWITCH 16A NON-F 3P UL508 (1)

Mouse over image to zoom, click to enlarge

  • RD16-3-508 BUS SWITCH 16A NON-F 3P UL508 (1)
  • RD16-3-508 BUS SWITCH 16A NON-F 3P UL508 (1)
  • RD16-3-508 BUS SWITCH 16A NON-F 3P UL508 (1)

Description: Bussmann Rotary Disconnect Switch, Non-Fused, Series: RD, 600 V AC, 16 A, 10 hp, 3 ph, 3 Pole, 65 kA Short Circuit, Front/Side Handle Actuator, DIN Rail/Panel Mounting, -20 to 70 deg C, 1.78 in L x 2.49 in W x 2.73 in H Dimensions

Manufacturer PN: RD16-3-508

UPC:  05171240247

Kendall Electric Inc PN: 2985716

Invoice Description:

RD16-3-508 BUS SWITCH 16A NON-F 3P UL508 (1)


SPEC SHEET

▸ See All in Open Rotary Control Disconnects


How Can We Make This Page Better?

Bussmann RD16-3-508 Non-Fused Rotary Disconnect Switch, 600 V AC, 16 A, 10 hp, 3 Poles

Log In for Pricing and Availability




Description

Bussmann series enclosed rotary disconnects provide an easy to install solution for providing a switch for power. Enclosed compact circuit protectors (CCP) offer some of the smallest options in the market for increasing protection and panel SCCR, available for 30 amp Class CC fuses, and up to 60A for class CF fuses. Other UL 98 options include up to 1200A non-fused and up to 800A Class L fused options. UL 508 load break disconnects for control and disconnecting means for motor applications.
Bussmann Rotary Disconnect Switch, Non-Fused, Series: RD, 600 V AC, 16 A, 10 hp, 3 ph, 3 Pole, 65 kA Short Circuit, Front/Side Handle Actuator, DIN Rail/Panel Mounting, -20 to 70 deg C, 1.78 in L x 2.49 in W x 2.73 in H Dimensions

Specifications

 Actuator Type Front/Side Handle
 Amperage Rating 16 A
 Application Stationary Machinery Equipment in Factory and Robotics Applications
 Brand Name Bussmann
 Dimensions 1.78 in L x 2.49 in W x 2.73 in H
 Horsepower 10 hp
 Manufacturer Part Number RD16-3-508
 Mounting Type DIN Rail/Panel
 Number of Poles 3
 Phase 3
 Series RD Series
 Short Circuit Current Rating 65 kA
 Standards/Approvals Not Applicable,RoHS Compliant
 Temperature Rating -20 to 70 deg C
 Type Non-Fused
 Video Links
 Voltage Rating 600 V AC

Features

▪ Suitable as motor disconnect
▪ Disconnect switches are front, right side or direct handle operable
▪ Fingersafe® design
