Hubbell
RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH

Mouse over image to zoom, click to enlarge

  • RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH
  • RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH
  • RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH
  • RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH
  • RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH

Description: Hubbell Wiring Device-Kellems, RC109W, Combination Toggle Switch, Standard Sized, 120 V AC, 15 A, 1800 W Wattage, 1 Pole, Amber Neon Pilot Lamp, 2-Position Contact Configuration, 15 A Contact, Snap Action, Threaded Mounting, Side Wire Terminal, -20 to 60 deg C, Composite, White, 1.32 in W x 1.53 in D x 4.2 in H Dimensions

Manufacturer PN: RC109W

UPC:  88377811003

Kendall Electric Inc PN: 3946166

Invoice Description:

RC109W HUBBELL COMBO, 15A SP TOG, PILOT/ILLUM, WH


SPEC SHEET

▸ See All in Switches & Lights


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems RC109W Standard Sized Combination Toggle Switch, 120 V AC, 15 A, 1800 W

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Hubbell Wiring Device-Kellems, RC109W, Combination Toggle Switch, Standard Sized, 120 V AC, 15 A, 1800 W Wattage, 1 Pole, Amber Neon Pilot Lamp, 2-Position Contact Configuration, 15 A Contact, Snap Action, Threaded Mounting, Side Wire Terminal, -20 to 60 deg C, Composite, White, 1.32 in W x 1.53 in D x 4.2 in H Dimensions

Specifications

 Amperage Rating 15 A
 Application Circuit Control and Indication Residential Applications
 Brand Name Hubbell Premise Wiring
 Color White
 Contact Configuration 2-Position
 Contact Rating 15 A
 Dimensions 1.32 in W x 1.53 in D x 4.2 in H
 Lamp Type Amber Neon Pilot
 Manufacturer Part Number RC109W
 Material Composite
 Mounting Threaded
 Number of Poles 1
 PART NUMBER KEYWORDS RC109W ; 9509711 ; 11838671 ; 12167221 ; 883778110030 ; 88377811003 ; 00883778110030 ; 0883778110030
 Standards/Approvals CSA Certified|RoHS Compliant|UL Listed|UL 20|NEMA WD1/WD5
 Temperature Rating -20 to 60 deg C
 Terminal Type Side Wire
 Type Standard Sized
 Video Links
 Voltage Rating 120 V AC
 Wattage 1800 W

Features

▪ Quiet snap action mechanism
▪ Self-grounding staple is standard
▪ Elongated strap with continuous plaster ears
