PSG120E24RM EATON POWER SUPPLY 120W 1PHASE 100-240V INPUT VOLTAG, 24VDC 5AMP REMOVABLE SCREW TERMINALS 50% BOOST POWER 50WX121HX117DMM

Mouse over image to zoom, click to enlarge

  • PSG120E24RM EATON POWER SUPPLY 120W 1PHASE 100-240V INPUT VOLTAG, 24VDC 5AMP REMOVABLE SCREW TERMINALS 50% BOOST POWER 50WX121HX117DMM
  • PSG120E24RM EATON POWER SUPPLY 120W 1PHASE 100-240V INPUT VOLTAG, 24VDC 5AMP REMOVABLE SCREW TERMINALS 50% BOOST POWER 50WX121HX117DMM
  • PSG120E24RM EATON POWER SUPPLY 120W 1PHASE 100-240V INPUT VOLTAG, 24VDC 5AMP REMOVABLE SCREW TERMINALS 50% BOOST POWER 50WX121HX117DMM

Description: EATON DC Power Supply, 1-Phase Switcher, Series: PSG, 100 to 240 V AC Input, 24 VDC Output, 120 W Power, 2.2/5 A, 47/63 Hz Frequency, DIN Rail Mounting, Metal Case, 1.9685 in Width, 3.8583 in Depth, 3 in Height

Manufacturer PN: PSG120E24RM

UPC:  78668552098

Kendall Electric Inc PN: 3455718

Invoice Description:

PSG120E24RM EATON POWER SUPPLY 120W 1PHASE 100-240V INPUT VOLTAG, 24VDC 5AMP REMOVABLE SCREW TERMINALS 50% BOOST POWER 50WX121HX117DMM


SPEC SHEET

▸ See All in DC Power Supplies


How Can We Make This Page Better?

EATON PSG120E24RM 1-Phase Switcher DC Power Supply, 100 to 240 V AC Input, 24 VDC Output, 120 W Power Rating, 2.2/5 A, DIN Rail Mount

Log In for Pricing and Availability




Description

The PSG line of general purpose power supplies is used in a wide variety of industrial control applications. Applications include communication networks, sensors, PLCs and many other electrical systems. Each model is equipped with the options of a rugged metal or plastic housing, heavy-duty screw or finger-safe terminals and a variety of protection features. The PSG line offers the flexibility of operating with a universal input voltage of 100–240 Vac. It also provides system protection and continuous operation during brief current surges of up to 150% of nominal current for components with high in-rush demands.
EATON DC Power Supply, 1-Phase Switcher, Series: PSG, 100 to 240 V AC Input, 24 VDC Output, 120 W Power, 2.2/5 A, 47/63 Hz Frequency, DIN Rail Mounting, Metal Case, 1.9685 in Width, 3.8583 in Depth, 3 in Height

Specifications

 Amperage Rating 2.2/5 A
 Application Electrical Assemblies, Panels and OEMs Applications
 Brand Name EATON
 Case Material Metal
 Depth 3.8583 in
 Frequency Rating 47/63 Hz
 Height 3 in
 Input Voltage 100 to 240 V AC
 Manufacturer Part Number PSG120E24RM
 Mounting Type DIN Rail
 Output Voltage 24 V DC
 Power Rating 120 W
 Series PSG
 Standards/Approvals cULus/UL 60950-1,EN Listed,UL 508,CSA Certified,IEC Rated,cUL Certified,RoHS Compliant,German Safety,CE Marked
 Type 1-Phase Switcher
 Video Links
 Width 1.9685 in

Features

▪ Redundancy modules keep loads up and running in the event of a device failure
▪ Buffer module has the stored power needed to keep loads running through a short duration power failure
▪ Fixed finger safe terminals
▪ >92% at 3 x 400 VAC and 3 x 500 VAC efficiency
▪ PSG480R24RM/PSG960R24RM with O-ring diode parallel operation
▪ 18 to 12 AWG wire conductors
▪ 150% power surge output
▪ MTBF up to >800000 hr ensures uptime and reliability
▪ Protection from overvoltage, over current and over temperature conditions
▪ Rugged aluminum and plastic housings provide the durability required to stand up to harsh environments
▪ All metal DIN rail mounting hardware
▪ LED indicating light for DC OK simplifies troubleshooting
▪ Conformal coated electronics
▪ Hazardous location class I, division 2 rated models
▪ NEC class 2 rated model
