MPDB67660 MERSEN PWR DIS BLK AL INT 310A AD 6

Mouse over image to zoom, click to enlarge

  • MPDB67660 MERSEN PWR DIS BLK AL INT 310A AD 6
  • MPDB67660 MERSEN PWR DIS BLK AL INT 310A AD 6

Description: Mersen Power Distribution Block, Intermediate Open Style, Series: MPDB, 1000 VAC/VDC, 250 A, 1 Primary Connections/Pole, 6 Secondary Connection/Pole, 6 AWG to 350 kcmil Wire, 100 kA Short Circuit, Polycarbonate, TiN Coated, Black, 1.72 in W x 5 in D x 3.25 in H Dimensions

Manufacturer PN: MPDB67660

UPC:  78200145281

Kendall Electric Inc PN: 4551963

Invoice Description:

MPDB67660 MERSEN PWR DIS BLK AL INT 310A AD 6


SPEC SHEET

▸ See All in Power Distribution Block Accessories


How Can We Make This Page Better?

Mersen MPDB67660 Intermediate Open Style Power Distribution Block, 1000 VAC/VDC, 250 A, 6 AWG to 350 kcmil Wire, Polycarbonate

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The Next Generation Power Distribution Block (PDB). Mersen power distribution blocks provide a safe and easy method of splicing cables, splitting primary power into secondary circuits and fulfilling requirements for fixed junction tap-off points. All blocks are UL and CSA approved while meeting spacing requirements for feeder and branch circuits in conjunction with UL508A and the National Electrical Code®. PDB options include single or dual conductor primary inputs and up to 30 secondary outputs. Specialty blocks are available allowing for up to 7 primary inputs. The MPDB series is offered in three size categories: miniature (MPDB62 and MPDB63 series), intermediate (MPDB66 and MPDB67 series), and large (MPDB68 and MPDB69 series), in both aluminum and copper.
Mersen Power Distribution Block, Intermediate Open Style, Series: MPDB, 1000 VAC/VDC, 250 A, 1 Primary Connections/Pole, 6 Secondary Connection/Pole, 6 AWG to 350 kcmil Wire, 100 kA Short Circuit, Polycarbonate, TiN Coated, Black, 1.72 in W x 5 in D x 3.25 in H Dimensions

Specifications

 Amperage Rating 250 A
 Application Cable Splicing, Splitting Primary Power into Secondary Circuits, Fixed Junction and Tap-Off Point Applications
 Brand Name Mersen
 Color Black
 Dimensions 1.72 in W x 5 in D x 3.25 in H
 Finish TiN Coated
 Manufacturer Part Number MPDB67660
 Material Polycarbonate
 Primary Connections Pole 1
 Secondary Connection Pole 6
 Series MPDB
 Short Circuit Current Rating 100 kA
 Standards/Approvals RoHS Compliant|UL 1953 File No. E352417|CSA Class 6228-01
 Type Intermediate Open Style
 Voltage Rating 1000 VAC/VDC

Features

▪ Adder poles can be stacked to form multi-pole units in the field without the use of tools, adder poles allow for customization of primary and secondary wire combinations
▪ Aluminum connectors accept both aluminum or copper wire while copper connectors accept copper wire only and all 1-piece tin plated
▪ Insulators are virtually unbreakable, made of glass-filled polycarbonate, see-through hinged safety covers are optional and provide a greater deg of safety and shock resistance where required, hinged covers can be installed without tools
▪ 1 in through air and 2 in over surface between uninsulated live parts of opposite polarity meets requirements for feeder and branch circuit applications of UL508A
▪ Polycarbonate safety covers provide dead-front protection
▪ Each cover has a test probe hole in the center for circuit checking
▪ Tin plated aluminum contact
▪ Adder pole
