Description: Square D™ PowerPact™ Molded Case Circuit Breaker, Type MGL, 600 V AC/250 V DC, 800 A, 50/60 Hz, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, M Frame, Electronic Trip, 300 to 800 A Trip, 3 Pole, 3 ph, Electronic Actuator, Lug, 3/0 AWG to 500 kcmil Wire, 40 deg C, 8.1 in L x 8.3 in W x 12.8 in H

Manufacturer PN: MGL36800

UPC:  78590157580

Kendall Electric Inc PN: 4000158

Invoice Description:

MGL36800 SQD MOLDED CASE CIRCUIT


SPEC SHEET

▸ See All in Molded Case Circuit Breakers


How Can We Make This Page Better?

Square D™ PowerPact™ MGL36800 Type MGL Molded Case Circuit Breaker, 600 V AC/250 V DC, 800 A, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, 3 Poles, Electronic Trip

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has lugs on both the line and load sides. This PowerPacT M, 800A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Square D™ PowerPact™ Molded Case Circuit Breaker, Type MGL, 600 V AC/250 V DC, 800 A, 50/60 Hz, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, M Frame, Electronic Trip, 300 to 800 A Trip, 3 Pole, 3 ph, Electronic Actuator, Lug, 3/0 AWG to 500 kcmil Wire, 40 deg C, 8.1 in L x 8.3 in W x 12.8 in H

Specifications

 Actuator Type Electronic
 Amperage Rating 800 A
 Application For providing overload and short circuit protection
 Brand Name Square D
 Connection Type Lug
 Dimensions 8.1 in L x 8.3 in W x 12.8 in H
 Frame M
 Frequency Rating 50/60 Hz
 Manufacturer Part Number MGL36800
 Number of Poles 3
 PART NUMBER KEYWORDS MGL36800 ; 8100572 ; 785901575801 ; 78590157580 ; 00785901575801 ; 0785901575801
 Phase 3
 Standards/Approvals Buy American Act Compliant|RoHS Compliant|CSA Certified|IEC Certified|UL Listed|PROP65: Cancer and Reproductive harm - www.P65warnings.ca.gov
 Temperature Rating 40 deg C
 Trip Range 300 to 800 A
 Type Type MGL
 Voltage Rating 600 V AC/250 V DC

Features

▪ Available in 2 or 3 pole design
▪ Standard 80% rating only
▪ Common mounting holes, handle locations, and trim dimensions
▪ Wide range of field installable accessories
