Description: Schneider Electric Motor Disconnect Switch, 220 to 600 V AC, 60 A, 20 hp, 40 hp, 3 ph, 3 Pole, NEMA 4X Enclosure, 8.27 in H x 4.94 in W x 4.37 in D Dimensions, Polycarbonate

Manufacturer PN: MD3604X

UPC:  60648019023

Kendall Electric Inc PN: 4000128

Invoice Description:

MD3604X SQD SWITCH MOTOR DISCONNECT


SPEC SHEET

▸ See All in Enclosed Rotary Disconnects


How Can We Make This Page Better?

Schneider Electric MD3604X Motor Disconnect Switch, 220 to 600 V AC, 60 A, 20 hp, 40 hp, 3 Poles

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

The MD motor disconnect switch is listed UL 508 Suitable for Motor Control (UL File E164864) and conforms to IEC standard 60947-3. It is in a compact NEMA 4X enclosure suitable for use in NEMA 1, 3, 3R, 4, 4X, and 12 applications. This three pole 60 A motor disconnect switch has a 20 HP rating at 240 VAC, a 40 HP rating at 480 VAC and a 40 HP rating at 600VAC. The red handle interlock prevents the removal of the cover when the switch is in the ON position. This MD motor disconnect switch has an extremely small footprint. It is 6.38 inches tall, 3.9 inches wide and 4.37 deep. Switch is UL listed and CSA certified.
Schneider Electric Motor Disconnect Switch, 220 to 600 V AC, 60 A, 20 hp, 40 hp, 3 ph, 3 Pole, NEMA 4X Enclosure, 8.27 in H x 4.94 in W x 4.37 in D Dimensions, Polycarbonate

Specifications

 Amperage Rating 60 A
 Application Washdown/Rugged Industrial Applications
 Brand Name Square D
 Dimensions 8.27 in H x 4.94 in W x 4.37 in D
 Enclosure NEMA 4X
 Horsepower 20 hp, 40 hp
 Manufacturer Part Number MD3604X
 Material Polycarbonate
 Number of Poles 3
 PART NUMBER KEYWORDS MD3604X ; 785901911814 ; 78590191181 ; 00785901911814
 Phase 3
 Standards/Approvals ECCN: EAR99|UL 508 File No. E164864
 Voltage Rating 220 to 600 V AC

Features

▪ Water-tight NEMA 4X
▪ Covers additional enclosure types
▪ Horsepower rated
▪ OSHA lockout/tagout compatible
