Description: Schneider Electric Square D™ Motor Disconnect Switch, 600 V AC, 30 A, 7-1/2 hp, 20 hp, 25 hp, 3 ph, 3 Pole, NEMA 4X Enclosure, 6.38 in H x 3.9 in W x 4.37 in D Dimensions, Polycarbonate

Manufacturer PN: MD3304X

UPC:  60648019022

Kendall Electric Inc PN: 4004670

Invoice Description:

MD3304X SQD SWITCH MOTOR DISCONNECT


SPEC SHEET

▸ See All in Enclosed Rotary Disconnects


How Can We Make This Page Better?

Schneider Electric Square D™ MD3304X Motor Disconnect Switch, 600 V AC, 30 A, 7-1/2 hp, 20 hp, 25 hp, 3 Poles

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

The MD motor disconnect switch is listed UL 508 Suitable for Motor Control (UL File E164864) and conforms to IEC standard 60947-3. It is in a compact NEMA 4X enclosure suitable for use in NEMA 1, 3, 3R, 4, 4X, and 12 applications. This three pole 30 A motor disconnect switch has a 7.5 HP rating at 240 VAC, a 20 HP rating at 480 VAC and a 25 HP rating at 600VAC. The red handle interlock prevents the removal of the cover when the switch is in the ON position. This MD motor disconnect switch has an extremely small footprint. It is 6.38 inches tall, 3.9 inches wide and 4.37 deep. Switch is UL listed and CSA certified.
Schneider Electric Square D™ Motor Disconnect Switch, 600 V AC, 30 A, 7-1/2 hp, 20 hp, 25 hp, 3 ph, 3 Pole, NEMA 4X Enclosure, 6.38 in H x 3.9 in W x 4.37 in D Dimensions, Polycarbonate

Specifications

 Amperage Rating 30 A
 Application Wash Down/Rugged Industrial Applications
 Brand Name Square D
 Dimensions 6.38 in H x 3.9 in W x 4.37 in D
 Enclosure NEMA 4X
 Horsepower 7-1/2 hp, 20 hp, 25 hp
 Manufacturer Part Number MD3304X
 Material Polycarbonate
 Number of Poles 3
 PART NUMBER KEYWORDS MD3304X ; 785901871712 ; 78590187171 ; 00785901871712
 Phase 3
 Standards/Approvals UL 508 File No. E164864|ECCN: EAR99
 Voltage Rating 600 V AC

Features

▪ Water-tight NEMA 4X
▪ Covers additional enclosure types
▪ Horsepower rated
▪ OSHA lockout/tagout compatible
