M633 SHAWMUT 63A DIS-SW

Mouse over image to zoom, click to enlarge

  • M633 SHAWMUT 63A DIS-SW
  • M633 SHAWMUT 63A DIS-SW

Description: Mersen Disconnect Switch, Front Operated Modular Non-Fusible, 600 V AC, 63 A, 15 hp, 30 hp, 2 hp, 7 hp, 50 Hz Frequency, 3 Pole, Handle Actuator, Base Mounting, Tunnel Terminal, -40 to 40 deg C, PA66/6

Manufacturer PN: M633

UPC:  60534055744

Kendall Electric Inc PN: 3735577

Invoice Description:

M633 SHAWMUT 63A DIS-SW


SPEC SHEET

▸ See All in Special Application Disconnects


How Can We Make This Page Better?

Mersen M633 Front Operated Modular Non-Fusible Disconnect Switch, 600 V AC, 63 A, 15 hp, 30 hp, 2 hp, 7 hp, 3 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The M-series Load Break Switch is the most compact industrial-grade switch on the market. Capable of making or breaking loads up to 600V (UL), it is suitable as a motor disconnect. Extremely compact and robust, these switches have a variety of mounting options including DIN-rail, base, or door-mounting. A wide assortment of handles, shafts and accessories is available to accommodate any installation requirement.
Mersen Disconnect Switch, Front Operated Modular Non-Fusible, 600 V AC, 63 A, 15 hp, 30 hp, 2 hp, 7 hp, 50 Hz Frequency, 3 Pole, Handle Actuator, Base Mounting, Tunnel Terminal, -40 to 40 deg C, PA66/6

Specifications

 Actuator Type Handle
 Amperage Rating 63 A
 Application For line of sight disconnect, electrical isolation, branch-circuit switch and motor disconnect
 Brand Name Mersen
 Frequency Rating 50 Hz
 Horsepower 15 hp, 30 hp, 2 hp, 7 hp
 Manufacturer Part Number M633
 Material PA66/6
 Mounting Type Base
 Number of Poles 3
 Standards/Approvals RoHS Compliant|UL 508|UL File No. E196672|IEC 60947-3|cULus Listed|CE Certified
 Temperature Rating -40 to 40 deg C
 Terminal Type Tunnel
 Type Front Operated Modular Non-Fusible
 Voltage Rating 600 V AC

Features

▪ Padlockable, double break, silver plated contacts
▪ 2 hp at 120 VAC, 7 hp at 240 VAC 1-phase, 15 hp at 240 VAC, 30 hp at 480 VAC, 30 hp at 600 VAC 3-phase horsepower rating
