Eaton
LPJ-110SP BUS LOW PEAK CLASS J 110A (1)

Mouse over image to zoom, click to enlarge

  • LPJ-110SP BUS LOW PEAK CLASS J 110A (1)
  • LPJ-110SP BUS LOW PEAK CLASS J 110A (1)
  • LPJ-110SP BUS LOW PEAK CLASS J 110A (1)

Description: Bussmann Low-Peak™ Time Delay Fuse, Current Limiting, Series: LPJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 110 A, 600 V AC/300 V DC, 300/100 kA Interrupt, Class: J, 10 s Response, Knife Blade Terminal, Holder Mount, Cartridge Body, Dual Element, Melamine, 1.63 in Dia x 5.75 in L Body Size

Manufacturer PN: LPJ-110SP

UPC:  05171252341

Kendall Electric Inc PN: 22717

Invoice Description:

LPJ-110SP BUS LOW PEAK CLASS J 110A (1)


SPEC SHEET

▸ See All in Class J Fuses


How Can We Make This Page Better?

Bussmann Low-Peak™ LPJ-110SP Current Limiting Time Delay Fuse, 110 A, 600 V AC/300 V DC, 300/100 kA, Class J, Cartridge Body

Log In for Pricing and Availability




Description

Bussmann Low-Peak™ Time Delay Fuse, Current Limiting, Series: LPJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 110 A, 600 V AC/300 V DC, 300/100 kA Interrupt, Class: J, 10 s Response, Knife Blade Terminal, Holder Mount, Cartridge Body, Dual Element, Melamine, 1.63 in Dia x 5.75 in L Body Size

Specifications

 Amperage Rating 110 A
 Application Branch Circuit Breaker Panelboard Mains, Industrial Control, Machinery Disconnects and Power Panelboard Applications
 Body Size 1.63 in Dia x 5.75 in L
 Body Type Cartridge
 Brand Name Bussmann
 Class J
 Element Dual
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number LPJ-110SP
 Material Melamine
 Mounting Type Holder
 Rejection Non Rejection Non-Rejection
 Response Time 10 s
 Series LPJ
 Standards/Approvals UL Listed ,CSA Certified,RoHS Compliant
 Terminal Type Knife Blade
 Type Current Limiting
 Video Links
 Voltage Rating 600 V AC/300 V DC

Features

▪ Long time delay minimizes needless fuse openings due to temporary overloads and transient surges
▪ Current limitation protects downstream components against damaging thermal and magnetic effects of short circuit currents
▪ Dual element fuses have lower resistance than ordinary fuses, hence they run cooler
▪ They can often be sized for back up protection against motor burnout from overload or single phasing if other overload protective devices fail
▪ Separate overload and short circuit elements provide time delay for sizing of high inrush loads linked with class J current limitation
▪ Selective coordination ratio of 2:1 (within Low-Peak® fuse family) prevents electrical shutdowns from extending beyond the failed circuit
▪ Series combination ratings with branch circuit breakers allows broad range of coverage, independent of breaker manufacturer
▪ Proper sizing can provide "No Damage" type 2 coordinated protection for NEMA® and IEC® motor controllers
▪ Space saving package for equipment down sizing
▪ Industry's only UL listed and CSA Certified fuse with a 300 kA interrupt rating that allows for simple, worry free installation in virtually any application
▪ Fast short circuit protection and dual element, time delay performance provide ultimate protection
▪ Reduces existing fuse inventory by up to 33% when upgrading to Low-Peak® fuses
▪ Consistent 2:1 ampacity ratios for all Low-Peak® fuses make selective coordination easy

Resources

 Catalog
 Catalog Page
 Product Data Sheet
