Eaton
LKN300 BUSS 250V LINK RL300 (5)

Mouse over image to zoom, click to enlarge

  • LKN300 BUSS 250V LINK RL300 (5)
  • LKN300 BUSS 250V LINK RL300 (5)
  • LKN300 BUSS 250V LINK RL300 (5)
  • LKN300 BUSS 250V LINK RL300 (5)

Description: Bussmann Super-Lag Fuse Link, Non-Current Limiting Renewable Class KS, Series: LKN, 250 V, 300 A, Rated Breaking Capacity: 10 kA, Timing Response: Time Lag, Holder Mount, For Use With: REN-300 Class H/K5 8.63 in L Fuse, 3.622 in L x 1.339 in W x 1.102 in H

Manufacturer PN: LKN-300

UPC:  05171213300

Kendall Electric Inc PN: 22625

Invoice Description:

LKN300 BUSS 250V LINK RL300 (5)


SPEC SHEET

How Can We Make This Page Better?

Bussmann Super-Lag LKN-300 Non-Current Limiting Renewable Class KS Fuse Link, 250 V, 300 A, For Use With REN-300 Class H/K5 8.63 in L Fuse

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann Super-Lag Fuse Link, Non-Current Limiting Renewable Class KS, Series: LKN, 250 V, 300 A, Rated Breaking Capacity: 10 kA, Timing Response: Time Lag, Holder Mount, For Use With: REN-300 Class H/K5 8.63 in L Fuse, 3.622 in L x 1.339 in W x 1.102 in H

Specifications

 Amperage Rating 300 A
 Application Industrial and Commercial Structure Applications, Safety and Security Systems
 Brand Name Bussmann
 Dimensions 3.622 in L x 1.339 in W x 1.102 in H
 Manufacturer Part Number LKN-300
 Mounting Type Holder
 PART NUMBER KEYWORDS LKN-300 ; LKN300 ; 7597030 ; 051712133005 ; 51712133005 ; 05171213300 ; 00051712133005 ; 5027590466172
 Rated Breaking Capacity 10 kA
 Series LKN
 Standards/Approvals RoHS Compliant
 Suitable For Use With REN-300 Class H/K5 8.63 in L Fuse
 Timing Response Time Lag
 Type Non-Current Limiting Renewable Class KS
 Video Links
 Voltage Rating 250 V

Features

▪ Designed for easy replacement
▪ No multiple links to complicate replacement
▪ Bussmann Super-Lag renewable fuses with longer time lag than other class H fuses of this type can better sustain overloads without needlessly opening
▪ Super lag fuses are used in circuits of industrial and commercial structures where maximum short circuit currents are of a low level (below 10 kA) and frequent outages dictate the economy of the "renewable" type fuse
▪ These fuses are generally sized at the ampere rating of non-inductive circuits and 300% for motor circuits
