LITTELFUSE FLSR025 600V RK5 TD FUSE

Mouse over image to zoom, click to enlarge

Description: Littelfuse® POWR-GARD® Time Delay Fuse, Current Limiting, Series: FLSR, Non-Indicating, Rejection, 25 A, 600 V AC/300 V DC, 200/20 kA Interrupt, Class: RK5, 50/60 Hz, 10 s Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Composite, 13/16 in Dia x 5 in L Body Size

Manufacturer PN: FLSR025

Kendall Electric Inc PN: 4522527

Invoice Description:

LITTELFUSE FLSR025 600V RK5 TD FUSE


SPEC SHEET

▸ See All in Class RK5 Fuses


How Can We Make This Page Better?

Littelfuse® POWR-GARD® FLSR025 FLSR Current Limiting Time Delay Fuse, 25 A, 600 V AC/300 V DC, 200/20 kA Interrupt, RK5 Class, Cylindrical Body

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Littelfuse® FLSR series fuses have been the superior UL Class RK5 dual element time delay fuses and are the most widely used Class of fuses. FLSR series fuses provide excellent protection for all types of circuits especially those containing motors. However, users and specifiers should consider the significant benefits offered by indicator fuses.
Littelfuse® POWR-GARD® Time Delay Fuse, Current Limiting, Series: FLSR, Non-Indicating, Rejection, 25 A, 600 V AC/300 V DC, 200/20 kA Interrupt, Class: RK5, 50/60 Hz, 10 s Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Composite, 13/16 in Dia x 5 in L Body Size

Specifications

 Amperage Rating 25 A
 Application Service Entrance Switches, Transformers, Switchboard Mains and Feeders, Motor Control Central Mains, Motor Branch Circuits and All General Purpose Circuits Applications
 Body Size 13/16 in Dia x 5 in L
 Body Type Cylindrical
 Brand Name Littelfuse®
 Class RK5
 Element Dual
 Frequency Rating 50/60 Hz
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number FLSR025
 Material Composite
 Mounting Type Holder
 PART NUMBER KEYWORDS FLSR025 ; FLSR025.T ; FLSR025T ; 8579687 ; 079458170726 ; 79458170726 ; 07945817072 ; 00079458170726
 Rejection Non Rejection Rejection
 Response Time 10 s
 Series FLSR
 Standards/Approvals UL 248-12|E81895|CSA LR29862|Federal Specification WF-1814|PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer
 Terminal Type Ferrule
 Type Current Limiting
 Voltage Rating 600 V AC/300 V DC

Features

▪ Reliable interruption of all over currents up to 200 kA
▪ Faster acting short circuit protection than any non-current limiting mechanical protective device
▪ Accurate and reliable - automated, precision manufactured and assembled parts ensure accurate, consistent response to overloads and short circuits
▪ 300 kA rms symmetrical self certified
▪ Bronze caps
▪ Industrial cylindrical cartridge fuses
