Schneider Electric
  • LAD4RCU SQD RC TRANSIENT SUPPRESSOR
  • LAD4RCU SQD RC TRANSIENT SUPPRESSOR
  • LAD4RCU SQD RC TRANSIENT SUPPRESSOR
  • LAD4RCU SQD RC TRANSIENT SUPPRESSOR
  • LAD4RCU SQD RC TRANSIENT SUPPRESSOR
  • LAD4RCU SQD RC TRANSIENT SUPPRESSOR

Description: Square D™ TeSys® D Coil Suppressor Module, Series: LAD4, 100 Hz Frequency, 110 to 250 V AC Coil, For Use With: LC1D09-D38 and LC1DT20-DT40 Contactor

Manufacturer PN: LAD4RCU

UPC:  38911038545

Kendall Electric Inc PN: 3999885

Invoice Description:

LAD4RCU SQD RC TRANSIENT SUPPRESSOR


SPEC SHEET

▸ See All in Relay Surge Suppressor Modules


How Can We Make This Page Better?

Square D™ TeSys® D LAD4RCU Coil Suppressor Module, 100 Hz, 110 to 250 V AC V Coil

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

TeSys Deca suppressor module, for LC1D09-D38, LC1DT20-DT40 contactors and CAD control relays. To be used with 110-250V AC control circuit voltage, it provides a RC protection limiting the transient voltage to 3 Uc max. Clip-on side mounting, overall size of the contactor is unchanged.
Square D™ TeSys® D Coil Suppressor Module, Series: LAD4, 100 Hz Frequency, 110 to 250 V AC Coil, For Use With: LC1D09-D38 and LC1DT20-DT40 Contactor

Specifications

 Application For use with RC circuits protection for circuits highly sensitive to high frequency interference applications
 Brand Name Square D
 Coil Voltage 110 to 250 V AC
 Frequency Rating 100 Hz
 Manufacturer Part Number LAD4RCU
 PART NUMBER KEYWORDS LAD4RCU ; 8088100 ; 785901213789 ; 78590121378 ; 03389110385458 ; 3389110385458
 Series LAD4
 Standards/Approvals RoHS Compliant|ECCN: EAR99
 Suitable For Use With LC1D09-D38 and LC1DT20-DT40 Contactor
