Acuity Brands
L7XR-R6 LITHONIA 6" IC/ NON-IC HOUSING FOR STANDARD 2 X 8" CONSTRUCTION, ALUMINUM REMODEL CAN, FOR (CI# 122H7H)

Mouse over image to zoom, click to enlarge

  • L7XR-R6 LITHONIA 6" IC/ NON-IC HOUSING FOR STANDARD 2 X 8" CONSTRUCTION, ALUMINUM REMODEL CAN, FOR (CI# 122H7H)
  • L7XR-R6 LITHONIA 6" IC/ NON-IC HOUSING FOR STANDARD 2 X 8" CONSTRUCTION, ALUMINUM REMODEL CAN, FOR (CI# 122H7H)
  • L7XR-R6 LITHONIA 6" IC/ NON-IC HOUSING FOR STANDARD 2 X 8" CONSTRUCTION, ALUMINUM REMODEL CAN, FOR (CI# 122H7H)

Description: Lithonia Lighting®, L7XR R6, Downlight Housing, Airtight Contractor Select, Series: L7XR, 120 V AC, 6-7/8 in Ceiling Opening, Incandescent Lamp, 26/42 W Lamp, 1 Lamps, IC/Non-IC Insulation, Ceiling Mounting, For Use With: REALITY™ ENERGY STAR® (ESL) Open Narrow Flange LED Module/P Series Open and Baffle Wide Flange LED Module, 6 in Diameter, 22-1/4 in Height, 11 in Width, 13 in Depth, Steel Housing Material, Nickel

Manufacturer PN: L7XRR6

UPC:  74597378970

Kendall Electric Inc PN: 2603424

Invoice Description:

L7XR-R6 LITHONIA 6" IC/ NON-IC HOUSING FOR STANDARD 2 X 8" CONSTRUCTION, ALUMINUM REMODEL CAN, FOR (CI# 122H7H)


SPEC SHEET

▸ See All in Recessed Lighting Housings


How Can We Make This Page Better?

Lithonia Lighting® L7XR R6 L7XR Airtight Contractor Select Downlight Housing, Incandescent Lamp, IC/Non-IC Insulation, 120 V AC, 6-7/8 in Ceiling Opening, Steel Housing

Log In for Pricing and Availability




Description

Recessed incandescent housings for 2x8 new construction. Approved for direct burial in insulation and all ceiling and wiring types.
Lithonia Lighting®, L7XR R6, Downlight Housing, Airtight Contractor Select, Series: L7XR, 120 V AC, 6-7/8 in Ceiling Opening, Incandescent Lamp, 26/42 W Lamp, 1 Lamps, IC/Non-IC Insulation, Ceiling Mounting, For Use With: REALITY™ ENERGY STAR® (ESL) Open Narrow Flange LED Module/P Series Open and Baffle Wide Flange LED Module, 6 in Diameter, 22-1/4 in Height, 11 in Width, 13 in Depth, Steel Housing Material, Nickel

Specifications

 Application Hospitality, Residential and Retail Applications
 Brand Name Lithonia Lighting®
 Ceiling Opening 6-7/8 in
 Color Nickel
 Depth 13 in
 Height 22-1/4 in
 Housing Material Steel
 Lamp Type Incandescent
 Lamp Wattage 26/42 W
 Manufacturer Part Number L7XR R6
 Mounting Type Ceiling
 Number of Lamps 1
 PART NUMBER KEYWORDS L7XR R6 ; L7XRR6 ; 122H7H ; 9847734 ; 10837211 ; 745973789704 ; 74597378970 ; 00745973789704
 Series L7XR
 Standards/Approvals cULus Listed
 Suitable For Use With REALITY™ ENERGY STAR® (ESL) Open Narrow Flange LED Module/P Series Open and Baffle Wide Flange LED Module
 Type Airtight Contractor Select
 Voltage Rating 120 V AC
 Width 11 in

Features

▪ Recessed incandescent housings for 2x8 new construction
▪ Approved for direct burial in insulation and all ceiling and wiring types
▪ Air-tight aluminum housing with heavy-gauge galvanized steel raceway arm
▪ Aluminum housing with three remodel clips for installation in existing plaster, sheet rock or mechanical ceilings
