Hubbell
L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598

Mouse over image to zoom, click to enlarge

  • L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598
  • L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598
  • L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598
  • L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598
  • L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598

Description: Hubbell Wiring Device-Kellems Twist-Lock® Locking Male Plug, 1-Phase Grounding Standard Sized Cord Mount, 250 V AC, 30 A, 2 Pole, 3 Wires, L6-30P NEMA Rating, Commercial/Industrial Grade, -40 to 60 deg C, Screw Terminal, Composite, Black

Manufacturer PN: L630P

UPC:  78358583598

Kendall Electric Inc PN: 2897396

Invoice Description:

L630P HUBBELL LKG PLG, 30A 250V, HUB PRO, L6-30P 78358583598


SPEC SHEET

▸ See All in Locking Plugs


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems Twist-Lock® L630P 1-Phase Grounding Standard Sized Cord Mount Locking Male Plug, 250 V AC, 30 A, 2 Poles, 3 Wires, Black

Log In for Pricing and Availability




Description

Hubbell® Pro™ locking devices provide a safe disconnect solution between an equipment load and a power source. These devices incorporate a locking interface that is engaged and disengaged simply by rotating the device assuring a safe and reliable electrical connection.
Hubbell Wiring Device-Kellems Twist-Lock® Locking Male Plug, 1-Phase Grounding Standard Sized Cord Mount, 250 V AC, 30 A, 2 Pole, 3 Wires, L6-30P NEMA Rating, Commercial/Industrial Grade, -40 to 60 deg C, Screw Terminal, Composite, Black

Specifications

 Amperage Rating 30 A
 Application For power connection applications
 Brand Name Hubbell Premise Wiring
 Color Black
 Grade Commercial/Industrial
 Manufacturer Part Number L630P
 Material Composite
 NEMA Rating L6-30P
 Number of Poles 2
 Number of Wires 3
 Standards/Approvals CSA Certified|RoHS Compliant|UL Listed
 Temperature Rating -40 to 60 deg C
 Terminal Type Screw
 Type 1-Phase Grounding Standard Sized Cord Mount
 Voltage Rating 250 V AC

Features

▪ Terminals identified in accordance with UL 498 (brass, white, green)
▪ 18 to 8 AWG flexible cord
▪ Ratings and NEMA identification are permanently marked on device
▪ Indoor dry unless protected by additional means
▪ 10 to 8 AWG wire
▪ Visible NEMA ratings
▪ Captive assembly screws
▪ Supertough® nylon body
▪ Impact modified nylon blade/contact holder
▪ Brass contacts/blade
▪ Withstands 3500 VAC per UL 498 dielectric voltage
▪ 600 VAC or 250 VDC maximum working voltage
▪ Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498
▪ Minimum 4.8 times rated current for 100 cycles overload
