Eaton
KTU-3000 BUSSMANN LIMITRON FAST ACTING FUSE CLASS L

Mouse over image to zoom, click to enlarge

  • KTU-3000 BUSSMANN LIMITRON FAST ACTING FUSE CLASS L
  • KTU-3000 BUSSMANN LIMITRON FAST ACTING FUSE CLASS L
  • KTU-3000 BUSSMANN LIMITRON FAST ACTING FUSE CLASS L
  • KTU-3000 BUSSMANN LIMITRON FAST ACTING FUSE CLASS L

Description: Bussmann Limitron™ Fuse, Current Limiting Fast Acting, Series: KTU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3000 A, 600 V, 200 kAIC Interrupt, Class: L, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Single Element, Melamine Glass Tube, 5 in Dia x 10-3/4 in L Body Size

Manufacturer PN: KTU-3000

UPC:  05171261330

Kendall Electric Inc PN: 4693146

Invoice Description:

KTU-3000 BUSSMANN LIMITRON FAST ACTING FUSE CLASS L


SPEC SHEET

▸ See All in Class L Fuses


How Can We Make This Page Better?

Bussmann Limitron™ KTU-3000 Current Limiting Fast Acting Fuse, 3000 A, 600 V, 200 kAIC Interrupt, L Class, Cartridge Body

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann's broad line of UL Class L fuses includes the KRP-C-SP Low-Peak family of fuses offering unsurpassed dual-element, current-limiting, time-delay performance and interrupting ratings of 300kA RMS Sym. Complementing the Low-Peak family are our Limitron products offering both Fast-acting and economical time-delay performance in our KTU, KLU, and KRP-CL products
Bussmann Limitron™ Fuse, Current Limiting Fast Acting, Series: KTU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3000 A, 600 V, 200 kAIC Interrupt, Class: L, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Single Element, Melamine Glass Tube, 5 in Dia x 10-3/4 in L Body Size

Specifications

 Amperage Rating 3000 A
 Application Industrial Facilities and Factories, Safety and Security Systems, Large Distribution Switchboards and Power Panelboards Applications
 Body Size 5 in Dia x 10-3/4 in L
 Body Type Cartridge
 Brand Name Bussmann
 Class L
 Element Single
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number KTU-3000
 Material Melamine Glass Tube
 Mounting Type Bolted-On
 Rejection Non Rejection Non-Rejection
 Series KTU
 Standards/Approvals CE Certified|CSA C22.2 File No.53787/248.10|NEC 110.9|RoHS Compliant|UL File No.E4273/248-10 Guide JDDZ
 Terminal Type Bolted Blade End
 Type Current Limiting Fast Acting
 Video Links
 Voltage Rating 600 V

Features

▪ Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
▪ Fast acting fuse helps prevent equipment damage caused by short circuit events
▪ O-ring seals maximize pressure build-up during current limiting action and ensure filter retention
▪ 99.9% pure silver links provide low watt loss with low operating temperature on normal current levels and minimizes total clearing it fault energy left through
▪ Ideal for critical industrial or commercial applications that have specific current limitation requirements
▪ Silver plated end bell
