Eaton
KTKR2/10 BUS 600V LIMITRON FUSE (1)

Mouse over image to zoom, click to enlarge

  • KTKR2/10 BUS 600V LIMITRON FUSE (1)
  • KTKR2/10 BUS 600V LIMITRON FUSE (1)

Description: Bussmann Limitron™ Fuse, Current Limiting Fast Acting Low Voltage, Series: KTK-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 0.2 A, 600 V, 200 kAIC Interrupt, Class: CC, Ferrule End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine Tube, 13/32 in Dia x 1-1/2 in L Body Size

Manufacturer PN: KTK-R-2/10

UPC:  05171242053

Kendall Electric Inc PN: 22513

Invoice Description:

KTKR2/10 BUS 600V LIMITRON FUSE (1)


SPEC SHEET

How Can We Make This Page Better?

Bussmann Limitron™ KTK-R-2/10 Current Limiting Fast Acting Low Voltage Fuse, 0.2 A, 600 V, 200 kAIC Interrupt, CC Class, Cartridge Body

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann's Class CC fuses set the standard in Class CC fuse performance in the industry. Recognized for their superior performance, Bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600v, 200,000a IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our Low Peak LP-CC fuses, the time delay of our FNQ-R's for your control transformer and similar control applications or the fast acting protection of our KTK-R Limitron fuses for specialized circuits such as lighting protection
Bussmann Limitron™ Fuse, Current Limiting Fast Acting Low Voltage, Series: KTK-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 0.2 A, 600 V, 200 kAIC Interrupt, Class: CC, Ferrule End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine Tube, 13/32 in Dia x 1-1/2 in L Body Size

Specifications

 Amperage Rating 0.2 A
 Application Industrial Facilities and Factories, Safety and Security Systems, Specialized Circuits, Branch Circuits, Street Lighting, Isolated and In-Line Fuse Holders Applications
 Body Size 13/32 in Dia x 1-1/2 in L
 Body Type Cartridge
 Brand Name Bussmann
 Class CC
 Element Single
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number KTK-R-2/10
 Material Melamine Tube
 Mounting Type Holder
 PART NUMBER KEYWORDS KTK-R-2/10 ; KTKR210 ; 7614039 ; 051712420532 ; 51712420532 ; 05171242053 ; 00051712420532 ; 5027590092289
 Rejection Non Rejection Rejection
 Series KTK-R
 Standards/Approvals CE Certified|CSA C22.2 File No.53787/248.4|RoHS Compliant|UL 248-14 File No.E19180 Guide JDYX
 Terminal Type Ferrule End
 Type Current Limiting Fast Acting Low Voltage
 Video Links
 Voltage Rating 600 V

Features

▪ Current limitation at class CC levels provides maximum component short circuit current protection
▪ 200 kA interrupt rating provides high ratings at all circuit locations
▪ Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
▪ Nickel plated bronze end caps
