KLU3000 BUSS DURA-LAG TIME DELAY FUSE 3000 AMP

Mouse over image to zoom, click to enlarge

  • KLU3000 BUSS DURA-LAG TIME DELAY FUSE 3000 AMP
  • KLU3000 BUSS DURA-LAG TIME DELAY FUSE 3000 AMP
  • KLU3000 BUSS DURA-LAG TIME DELAY FUSE 3000 AMP
  • KLU3000 BUSS DURA-LAG TIME DELAY FUSE 3000 AMP

Description: Bussmann Limitron™ Fuse, Current Limiting Time Delay, Series: KLU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3000 A, 600 V, 200 kAIC Interrupt, Class: L, 5 s at 500% Response, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Single Element, Fiberglass/Melamine, 5 in Dia x 10-3/4 in L Body Size

Manufacturer PN: KLU-3000

UPC:  05171249703

Kendall Electric Inc PN: 22483

Invoice Description:

KLU3000 BUSS DURA-LAG TIME DELAY FUSE 3000 AMP


SPEC SHEET

▸ See All in Class L Fuses


How Can We Make This Page Better?

Bussmann Limitron™ KLU-3000 Current Limiting Time Delay Fuse, 3000 A, 600 V, 200 kAIC Interrupt, L Class, Cartridge Body

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann's broad line of UL Class L fuses includes the KRP-C-SP Low-Peak family of fuses offering unsurpassed dual-element, current-limiting, time-delay performance and interrupting ratings of 300kA RMS Sym. Complementing the Low-Peak family are our Limitron products offering both Fast-acting and economical time-delay performance in our KTU, KLU, and KRP-CL products
Bussmann Limitron™ Fuse, Current Limiting Time Delay, Series: KLU, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 3000 A, 600 V, 200 kAIC Interrupt, Class: L, 5 s at 500% Response, Bolted Blade End Terminal, Bolted-On Mount, Cartridge Body, Single Element, Fiberglass/Melamine, 5 in Dia x 10-3/4 in L Body Size

Specifications

 Amperage Rating 3000 A
 Application Industrial Facilities and Factories, Safety and Security Systems, Large Distribution Switchboards, Large Machinery Disconnects and Power Panelboards Applications
 Body Size 5 in Dia x 10-3/4 in L
 Body Type Cartridge
 Brand Name Bussmann
 Class L
 Element Single
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number KLU-3000
 Material Fiberglass/Melamine
 Mounting Type Bolted-On
 PART NUMBER KEYWORDS KLU-3000 ; KLU3000 ; 7619961 ; 051712497039 ; 51712497039 ; 05171249703 ; 00051712497039
 Rejection Non Rejection Non-Rejection
 Response Time 5 s at 500%
 Series KLU
 Standards/Approvals CE Certified|CSA C22.2 File No.53787/248.10|NEC 110.9|RoHS Compliant|UL File No.E4273/248-10 Guide JDDZ
 Terminal Type Bolted Blade End
 Type Current Limiting Time Delay
 Video Links
 Voltage Rating 600 V

Features

▪ Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
▪ Fast acting fuse helps prevent equipment damage caused by short circuit events
▪ Copper links result in a minimum 5 s time delay at 500% ampere rating
