Eaton
KAC175 BUS 600V FUSE

Mouse over image to zoom, click to enlarge

  • KAC175 BUS 600V FUSE
  • KAC175 BUS 600V FUSE
  • KAC175 BUS 600V FUSE
  • KAC175 BUS 600V FUSE
  • KAC175 BUS 600V FUSE

Description: Bussmann Tron® High Speed Fuse, North American Style Rectifier, Series: KAC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 175 A, 600 V AC, 200 kAIC Interrupt, Blade End Terminal, Stud Mount, Cartridge Body Type, Single Element, Fiberglass, 1.5 in Dia x 5.14 in L Body Size

Manufacturer PN: KAC-175

UPC:  05171247175

Kendall Electric Inc PN: 22390

Invoice Description:

KAC175 BUS 600V FUSE


SPEC SHEET

How Can We Make This Page Better?

Bussmann Tron® KAC-175 North American Style Rectifier High Speed Fuse, 175 A, 600 V AC, 200 kAIC Interrupt, Cartridge Body

Log In for Pricing and Availability




Description

High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling environments, or heavy duty applications.
Bussmann Tron® High Speed Fuse, North American Style Rectifier, Series: KAC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 175 A, 600 V AC, 200 kAIC Interrupt, Blade End Terminal, Stud Mount, Cartridge Body Type, Single Element, Fiberglass, 1.5 in Dia x 5.14 in L Body Size

Specifications

 Amperage Rating 175 A
 Application Industrial Facilities and Factory Facilities, Safety and Security Systems, DC Common Bus, DC Drives, Power Converters, Rectifiers and Reduced Voltage Starters Applications
 Body Size 1.5 in Dia x 5.14 in L
 Body Type Cartridge
 Brand Name Bussmann
 Element Single
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number KAC-175
 Material Fiberglass
 Mounting Type Stud
 PART NUMBER KEYWORDS KAC-175 ; KAC175 ; 7619447 ; 051712471756 ; 51712471756 ; 05171247175 ; 00051712471756
 Rejection Non Rejection Non-Rejection
 Series KAC
 Standards/Approvals CE Certified|UL Recognized to Guide No. JFHR2 File No. E56413
 Terminal Type Blade End
 Type North American Style Rectifier
 Video Links
 Voltage Rating 600 V AC

Features

▪ Low arc voltage and low energy let-through
▪ Excellent DC performance
▪ Low wattage loss
▪ Superior cycling capability
▪ North American style bolted tags and flush end high speed fuses
▪ Low arc voltage, superior cycling capability

Resources

 Catalog Page
 Product Data Sheet
