Panduit

IURH6X04BL-UG PAN INDUST CAT6A 600V AWM 4 PAIR 23/1

Mouse over image to zoom, click to enlarge

Description: Panduit® IndustrialNet™ Cable, Cat 6a, 600 V, 4 Pairs Conductors, U/UTP Solid Copper Conductor, 23 AWG Conductor, 0.34 in OD, 305 m Length, 1 Strands, Polyethylene Insulation, PVC Jacket, Black Jacket, -40 to 167 deg F

Manufacturer PN: IURH6X04BL-UG

UPC: 61305675549

Kendall Electric Inc PN: 4541165

Invoice Description:

IURH6X04BL-UG PAN INDUST CAT6A 600V AWM 4 PAIR 23/1

SPEC SHEET

▸ See All in Paired-Conductor Cables - Unshielded

How Can We Make This Page Better?

Panduit® IndustrialNet™ IURH6X04BL-UG Cat 6a Cable, 600 V, (4 Pairs) 23 AWG U/UTP Solid Copper Conductor, 305 m L

Note: Lead times are estimates only

Description Specifications Features Resources

Description

Panduit® IndustrialNet™ Cable, Cat 6a, 600 V, 4 Pairs Conductors, U/UTP Solid Copper Conductor, 23 AWG Conductor, 0.34 in OD, 305 m Length, 1 Strands, Polyethylene Insulation, PVC Jacket, Black Jacket, -40 to 167 deg F

Specifications

Application	Industrial Ethernet Based and Communications Network Applications
Brand Name	Panduit®
Conductor Size	23 AWG
Conductor Type	U/UTP Solid Copper
Insulation Material	Polyethylene
Jacket Color	Black
Jacket Material	PVC
Length	305 m
Manufacturer Part Number	IURH6X04BL-UG
Number of Conductors	4 Pairs
PART NUMBER KEYWORDS	IURH6X04BL-UG ; IURH6X04BLUG ; 14864311 ; 613056755499 ; 61305675549 ; 00613056755499 ; 0613056755499
Standards/Approvals	ANSI/TIA-568.2-D Category 6A and ODVA EtherNet/IP^ standards, Category 6A at swept frequencies up to 500 MHz, UL AWM Style 21047 (75Â°C 600V), Oil Res and Sun Res, UL 444 Sun Res, UL 1666 CMR
Strands	1
Temperature Rating	-40 to 167 deg F
Type	Cat 6a
Video Links
Voltage Rating	600 V

Features

▪ Oil and sunlight performance rated cable jacket, delivers enhanced chemical resistance and mechanical performance

▪ Ethernet/IP compliant design provides performance levels required to support industrial network applications

▪ 600 V AWM rated jacket approved for control panel or on-machine applications when the space is shared with 600 V high voltage power cables, required for UL 508A
