ABB
ICS641 ITB 6 TO 6 INS SPLICE

Mouse over image to zoom, click to enlarge

  • ICS641 ITB 6 TO 6 INS SPLICE
  • ICS641 ITB 6 TO 6 INS SPLICE
  • ICS641 ITB 6 TO 6 INS SPLICE
  • ICS641 ITB 6 TO 6 INS SPLICE

Description: Blackburn® Service Entrance Splice, Insulated, Series: ICS, ACSR/Solid/Stranded Conductor, 6 to 4 AWG Conductor, Die Code: 5/8, 2-25/32 in Length, Crimp/Compression Connector, Specifications: 2-Conductor, 0.184 to 0.204 in Dia End A and End B, Aluminum, Blue

Manufacturer PN: ICS64-1

UPC:  78378610236

Kendall Electric Inc PN: 38985

Invoice Description:

ICS641 ITB 6 TO 6 INS SPLICE


SPEC SHEET

▸ See All in Overhead Service Entrance Sleeves


How Can We Make This Page Better?

Blackburn® ICS64-1 Insulated Service Entrance Splice, 6 to 4 AWG ACSR/Solid/Stranded Conductor, Die Code: 5/8, 2-25/32 in L, Aluminum

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Blackburn® stands for quality and reliability as a supplier of materials to connect overhead distribution power lines and equipment.
Blackburn® Service Entrance Splice, Insulated, Series: ICS, ACSR/Solid/Stranded Conductor, 6 to 4 AWG Conductor, Die Code: 5/8, 2-25/32 in Length, Crimp/Compression Connector, Specifications: 2-Conductor, 0.184 to 0.204 in Dia End A and End B, Aluminum, Blue

Specifications

 Application For standard conductor splice and combination of aluminum to aluminum and aluminum to copper conductors
 Brand Name Blackburn
 Color Blue
 Conductor Size 6 to 4 AWG
 Conductor Type ACSR/Solid/Stranded
 Connector Type Crimp/Compression
 Die Code 5/8
 Fitting Type Crimp/Compression
 Length 2-25/32 in
 Manufacturer Part Number ICS64-1
 Material Aluminum
 PART NUMBER KEYWORDS ICS64-1 ; ICS641 ; 7TAA267180R0003 ; 10902832 ; 783786102365 ; 78378610236 ; 00783786102365
 Series ICS
 Specifications 2-Conductor, 0.184 to 0.204 in Dia End A and End B
 Standards/Approvals RUS Accepted. Complies with ANSI C119.4 when properly installed on Aluminum-to-Aluminum or Aluminum-to-Copper Conductors / RUS Accepted. Complies with ANSI C119.4 when properly installed on Aluminum-to-Aluminum or Aluminum-to-Copper Conductors
 Type Insulated

Features

▪ Complies with ANSI C119.4 when properly installed on aluminum-to-aluminum or aluminum-to-copper conductors
▪ Constructed from aluminum for high conductivity
▪ Solid center barriers and large chamfers for easy cable insertion
▪ Tough stabilized nylon sleeves resist installing tool pressure and provide reliable 600 VAC insulation
▪ Prefilled with oxide-inhibitor to prevent oxidation and keep out moisture
▪ All splices are Color coded and marked with strip lengths, installation die codes and compression locations providing easy identification for easy installation
▪ Splices have colored end caps to make identification easy
▪ All seasons environmental conditions
▪ 6 AWG ACSR, 6 AWG stranded, 4 AWG solid end A and 6 AWG ACSR, 6 AWG stranded, 4 AWG solid end B conductor
▪ 5/8 in die series, U-BG B58CS hydraulic dies, 5/8 (OD58 tool) peach, BG, W-BG, G, TU mechanical dies
