Acuity Brands
I320-TBTS M20 IOTA FLUORESCENT EMERGENCY BACKUP BALLAST (CI# 2657WT)

Mouse over image to zoom, click to enlarge

Description: IOTA® Emergency Ballast, Reduced Profile, Series: AC Series, 14 to 54 W Lamp, 3.5 W, 120/277 V AC, 60 Hz, Instant/Rapid Start, 1 Lamp, Bi-Pin Single Lamp Base, 0 to 50 deg C, Galvanized Steel, 13 in L x 2.2 in W x 1.25 in H

Manufacturer PN: I320TBTSM20

UPC:  04023250693

Kendall Electric Inc PN: 2377469

Invoice Description:

I320-TBTS M20 IOTA FLUORESCENT EMERGENCY BACKUP BALLAST (CI# 2657WT)


SPEC SHEET

▸ See All in Fluorescent Emergency Ballasts


How Can We Make This Page Better?

IOTA® I-320 AC Series Reduced Profile Emergency Ballast, 14 to 54 W Lamp, 120/277 V AC, Instant/Rapid

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The I-320 series AC fluorescent emergency ballast from IOTA engineering allows the same fixture to be used for both normal and emergency operation. In the event of a power failure, the I-320 switches to the emergency mode and operates one of the existing lamps for 90 minutes. The unit contains a battery, charger, and inverter circuit in a single can and can be mounted in the wireway or on top of the fixture. The I-320 can be used with most 2'-4' T8 and 2'-4' 14W to 54W T5 fluorescent lamps, with an initial output of up to 1350 lumens for one lamp. The I-320 utilizes AC output to ensure compatibility with new lamp technologies and features lamp selector leads for optimizing light output for designated lamp type. The I-320 delivers high performance in a slim design and is ideal for use in fixtures where ballast compartment space is limited. The I-320 is suitable for use in damp locations and in enclosed and gasketed fixtures.
IOTA® Emergency Ballast, Reduced Profile, Series: AC Series, 14 to 54 W Lamp, 3.5 W, 120/277 V AC, 60 Hz, Instant/Rapid Start, 1 Lamp, Bi-Pin Single Lamp Base, 0 to 50 deg C, Galvanized Steel, 13 in L x 2.2 in W x 1.25 in H

Specifications

 Application For use in damp locations, plenum and in enclosed and gasketed fixtures
 Brand Name IOTA®
 Dimensions 13 in L x 2.2 in W x 1.25 in H
 Frequency Rating 60 Hz
 Includes Test Switch/Charge Indicator Accessory Kit
 Lamp Base Type Bi-Pin Single
 Lamp Wattage 14 to 54 W
 Manufacturer Part Number I-320
 Material Galvanized Steel
 Number of Lamps 1
 Series AC Series
 Standards/Approvals UL Listed|cUL Listed|RoHS Compliant
 Start Type Instant/Rapid
 Temperature Range 0 to 50 deg C
 Type Reduced Profile
 Voltage Rating 120/277 V AC
 Wattage 3.5 W
