Hubbell
HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990

Mouse over image to zoom, click to enlarge

  • HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990
  • HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990
  • HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990
  • HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990
  • HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990

Description: Hubbell Wiring Device-Kellems, HBL5260WSA, Surge Protection Receptacle, Decorator Duplex Specification Grade Standard, 125 V AC, 15 A, 60 Hz Frequency, 1 ph, Straight Blade Outlet, Class: Common/Normal Mode, 5 ns Response, Indicators: Visual, Screw Terminal Connection, Threaded Mounting, 1.72 in W x 1.6 in D x 4.04 in H Size, 32 to 140 deg F Operating, Composite, White, Environmental Conditions: UL 94 V-2 Flammability Rated

Manufacturer PN: HBL5260WSA

UPC:  78358521990

Kendall Electric Inc PN: 3333360

Invoice Description:

HBL5260WSA HUBBELL DUP SPD RCPT, 15A 125V, 5-15R, WH 78358521990


SPEC SHEET

▸ See All in Straight Blade Surge Suppressions


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems HBL5260WSA Decorator Duplex Specification Grade Standard Surge Protection Receptacle, 125 V AC, 15 A, 60 Hz, 1 Phase

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Hubbell® offers a broad range SPD receptacles with technology that is unsurpassed. Inside Hubbell® SPD receptacles are two 22 mm square MOVs providing 240 J of surge protection for each mode. The nylon component shield protects the printed circuit board from contaminants. An all glass, conformably coated PC board provides superior moisture immunity for longer life in humid environments.
Hubbell Wiring Device-Kellems, HBL5260WSA, Surge Protection Receptacle, Decorator Duplex Specification Grade Standard, 125 V AC, 15 A, 60 Hz Frequency, 1 ph, Straight Blade Outlet, Class: Common/Normal Mode, 5 ns Response, Indicators: Visual, Screw Terminal Connection, Threaded Mounting, 1.72 in W x 1.6 in D x 4.04 in H Size, 32 to 140 deg F Operating, Composite, White, Environmental Conditions: UL 94 V-2 Flammability Rated

Specifications

 Amperage Rating 15 A
 Brand Name Hubbell Premise Wiring
 Class Common/Normal Mode
 Color White
 Connection Screw Terminal
 Environmental Conditions UL 94 V-2 Flammability Rated
 Frequency Rating 60 Hz
 Manufacturer Part Number HBL5260WSA
 Material Composite
 Mounting Threaded
 Operating Temperature 32 to 140 deg F
 Outlet Straight Blade
 Phase 1
 Response Time 5 ns
 Size 1.72 in W x 1.6 in D x 4.04 in H
 Standards/Approvals CSA C22.2 No. 42|UL 498/1449 File No. E2186|UL94 V-2 Flammability Rating
 Type Decorator Duplex Specification Grade Standard
 Type of Indicators Visual
 Voltage Rating 125 V AC

Features

▪ Automatic self-grounding staple
▪ Distinctive surge symbol provides quick identification
▪ Power-on indicator light verifies that power is available
▪ Alert alarm sounds when surge protection is no longer functioning
