Hubbell
HBL415S HUBBELL 15A 125V BLUE SURGE 4-PLEX NEMA 5-15R 78358501785

Mouse over image to zoom, click to enlarge

Description: Hubbell Wiring Device-Kellems SpikeShield® Circuit Guard® 4-PLEX®, HBL415S, Surge Suppression Receptacle, Duplex Specification Grade Standard, 125 V AC, 15 A, 60 Hz Frequency, 1 ph, Straight Blade Outlet, Class: Common/Normal Mode, 5 ns Response, Indicators: LED, Screw Terminal Connection, Threaded Mounting, 0.92 in W x 4.3 in D x 4.3 in H Size, -40 to 75 deg C Operating, Polycarbonate, Blue

Manufacturer PN: HBL415S

UPC:  78358501785

Kendall Electric Inc PN: 2185021

Invoice Description:

HBL415S HUBBELL 15A 125V BLUE SURGE 4-PLEX NEMA 5-15R 78358501785


SPEC SHEET

How Can We Make This Page Better?

Hubbell Wiring Device-Kellems SpikeShield® Circuit Guard® 4-PLEX® HBL415S Duplex Specification Grade Standard Surge Suppression Receptacle, 125 V AC, 15 A, 60 Hz, 1 Phase

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Hubbell Wiring Device-Kellems SpikeShield® Circuit Guard® 4-PLEX®, HBL415S, Surge Suppression Receptacle, Duplex Specification Grade Standard, 125 V AC, 15 A, 60 Hz Frequency, 1 ph, Straight Blade Outlet, Class: Common/Normal Mode, 5 ns Response, Indicators: LED, Screw Terminal Connection, Threaded Mounting, 0.92 in W x 4.3 in D x 4.3 in H Size, -40 to 75 deg C Operating, Polycarbonate, Blue

Specifications

 Amperage Rating 15 A
 Application Indoor Dry Environment
 Brand Name Hubbell Premise Wiring
 Class Common/Normal Mode
 Color Blue
 Connection Screw Terminal
 Frequency Rating 60 Hz
 Manufacturer Part Number HBL415S
 Material Polycarbonate
 Mounting Threaded
 Operating Temperature -40 to 75 deg C
 Outlet Straight Blade
 PART NUMBER KEYWORDS HBL415S ; 8946844 ; 11826667 ; 783585017853 ; 78358501785 ; 00783585017853 ; 0783585017853
 Phase 1
 Response Time 5 ns
 Size 0.92 in W x 4.3 in D x 4.3 in H
 Standards/Approvals UL 1449/498 File No. E2186 3rd Edition|UL94 V-2 Flammability Rating|CSA C22.2 No. 42
 Type Duplex Specification Grade Standard
 Type of Indicators LED
 Voltage Rating 125 V AC

Features

▪ Easily accessible break-off tabs for split wiring
▪ Three conductors energize all four outlets
▪ Triple wipe contacts
▪ Surge supression with lights, 80 J6500A per mode
▪ Anchor hole and loop feature secures solid wire for fast, easy terminations
