Hubbell
HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119

Mouse over image to zoom, click to enlarge

  • HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119
  • HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119
  • HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119
  • HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119
  • HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119

Description: Hubbell Wiring Device-Kellems, HBL14W47A, Straight Blade Plug, 1-Phase Standard Watertight Cord Mount, 125 V AC, 15 A, 1/2 hp, 2 Pole, 3 Wires, 5-15P NEMA Rating, Commercial/Industrial Grade, NEMA 4/4X/6/6P/12 Enclosure, 3/8 to 5/8 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Elastomer/Composite, Yellow, 1.85 in Dia x 3.16 in L Dimensions

Manufacturer PN: HBL14W47A

UPC:  78358513119

Kendall Electric Inc PN: 3496110

Invoice Description:

HBL14W47A HUBBELL WATERTIGHT PLUG NEMA 5-15P, 15A/125V 78358513119


SPEC SHEET

▸ See All in Straight Blade Plugs


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems HBL14W47A 1-Phase Standard Watertight Cord Mount Straight Blade Plug, 125 V AC, 15 A, 2 Poles, 3 Wires, Yellow

Log In for Pricing and Availability




Description

Straight Blade Devices, Thermoplastic Elastomer Water Tight, Industrial/Commercial Grade, Straight, 2-Pole 3-Wire Grounding, 15A 125V, 5-15P, Yellow, Single Pack.
Hubbell Wiring Device-Kellems, HBL14W47A, Straight Blade Plug, 1-Phase Standard Watertight Cord Mount, 125 V AC, 15 A, 1/2 hp, 2 Pole, 3 Wires, 5-15P NEMA Rating, Commercial/Industrial Grade, NEMA 4/4X/6/6P/12 Enclosure, 3/8 to 5/8 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Elastomer/Composite, Yellow, 1.85 in Dia x 3.16 in L Dimensions

Specifications

 Amperage Rating 15 A
 Brand Name Hubbell Premise Wiring
 Color Yellow
 Cord Diameter 3/8 to 5/8 in
 Dimensions 1.85 in Dia x 3.16 in L
 Enclosure NEMA 4/4X/6/6P/12
 Grade Commercial/Industrial
 Horsepower 1/2 hp
 Manufacturer Part Number HBL14W47A
 Material Elastomer/Composite
 NEMA Rating 5-15P
 Number of Poles 2
 Number of Wires 3
 PART NUMBER KEYWORDS HBL14W47A ; 13029028 ; 13490819 ; 783585131191 ; 78358513119 ; 00783585131191 ; 0783585131191
 Standards/Approvals UL 498|ANSI Specified|CSA C22.2 No. 42 Certified|NEMA WD1/WD6|RoHS Compliant
 Temperature Rating -40 to 75 deg C
 Terminal Type Screw
 Type 1-Phase Standard Watertight Cord Mount
 Video Links
 Voltage Rating 125 V AC

Features

▪ Smooth body design minimizes collection points simplifying thewash down process
▪ Strain relief nut always seals on the body, minimizing debris collection
▪ Stainless steel hardware and corrosion-resistant connection points
